DS3800HPCA1F1E

About the DS3800HPCA1F1E

The DS3800HPCA1F1E is part of the Speedtronic Mark IV Line. This line is created by GE (General Electric). The DS3800HPCA1F1E is considered a digital pulse circuit board. This board easily and quickly installs with two tiny screws and a pair of small clips. One edge of the DS3800HPCA1F1E has an edge labeled with A through H and the letter J. There is a small inverted triangle separating the letters. The DS3800HPCA1F1E has five small LEDs. Four are clustered together and are red. The fifth is yellow and stands alone. Next to the yellow LED is a small red square which houses a metal switch. There are a series of different spaced and colored diodes. There are forty gold diodes, a silver diode, and a tiny black diode. The DS3800HPCA1F1E also has forty resistors. These resistors carry and hold the energy that flows through the board. Each resistor has up to five different colored bands. These bands are the code to figure out how much energy each resistor can withstand. The DS3800HPCA1F1E also has twenty-seven EPROMs and six EEPROMs. These hold all the data and programs for the DS3800HPCA1F1E. The EPROMs can be re-programmed as needed where the EEPROMs cannot. The EEPROMs and EPROM are placed in four rows. Each row has a thin metal partition. The DS3800HPCA1F1E has a black connection port along one edge. Each piece of the DS3800HPCA1F1E is labeled with the appropriate letter and numbers. The DS3800HPCA1F1E also has its part number printed on it, along with General Electric’s emblem and where the board was assembled.
