About the DS3800HPIB1G1E
This DS3800HPIB1G1E printed circuit board product offering from General Electric was originally designed and manufactured, as stated above, specifically for the Mark IV Turbine Control System Series. The Mark IV Series that this DS3800HPIB1G1E printed circuit board or PCB for short belongs to is something of a self-explanatory General Electric product series within their Mark Series Product Suite, as it it exists with a series of specific applications in the control and management systems of General Electric-compatible gas and steam turbines. This unfortunately has not yet been expanded to contain the wind turbine applications standardized to later General Electric Mark Series iterations such as the Mark VI Turbine Control System Series that would be released soon. While this DS3800HPIB1G1E product's Mark IV Series' may have something of a restricted set of potential applications, it is still quite the highly-demanded GE Mark product series within its larger automated industrial promotional community; given the fact that it is one of General Electric's final-developed Mark product series to take advantage of the patented Speedtronic control system technology first seen with the rollout of the Mark I Series in the mid to later 1960s. This DS3800HPIB1G1E product is likely not the originally-produced device of its specific Mark IV Series functionality.
Hardware Tips and Specifications
The DS3800HPIB1G1E is a board that is part of in the Speedtronic Mark IV Turbine Series. This board is rather large in size and is produced by General Electric (GE). The DS3800HPIB1G1E General Electric’s seal and was made in America. The DS3800HPIB1G1E has around sixty banded resistors. The bands identify them as a resistor and how much energy they can contain. There are almost seventy different diodes of varying types and colors. The range in color from silver, blue, and faint orange. There are six black components as well with one flat side. The DS3800HPIB1G1E also has eight brick red towers. There are also eight slim golden yellow capacitors. The DS3800HPIB1G1E has a lot of data and programming storage with the combination of forty-six EEPROM and EPROMs. If the data needs to be upgraded it can be done through the EPROM. The board also features labels along the side to match up where is fits in the existing system. One side is labeled one through eight while the other is marked A through J. To secure the DS3800HPIB1G1E in place there are twelve places to put in a screw mount. There are over thirty-five red LEDs on the face of the board. There is also a small switch. The DS3800HPIB1G1E comes with a total of nine separate connection points for different wiring harnesses. All connection points are compatible with a female harness.
AX Control has an enthusiastic informed staff. The staff at AX Control is delighted to be your go-to for your automation needs. Generally, any capacitor, resistor, and transistor in this DS3800HPIB1G1E device's normal assembly is part of a larger, series-standardized voltage limitation strategy. Any of the previously-mentioned hardware component and component specification details listed above have been sourced from a direct visual inspection by one of our passionate and experienced circuit board service technicians. This research method was deemed necessary as the Mark IV Series is a legacy product series not surrounded by a plethora of original instructional documentation online. With this lack being identified, the DS3800HPIB1G1E functional product number itself can be embraced as a fine source of DS3800HPIB1G1E Board hardware information; given the fact that it codes for relevant DS3800HPIB1G1E PCB hardware details in a set of consecutive functional naming elements as designed by General Electric. For instance, the DS3800HPIB1G1E functional product number begins with the dual-functional DS3800 series tag delegating both this DS3800HPIB1G1E product's domestic location of original GE manufacture on top of its normal style of Mark IV Series assembly. This initial tag is followed in the DS3800HPIB1G1E functional product number through an instance of the HPIB functional product acronym, which was created to exist as a convenient conversational and promotional functional representation of the lengthy DS3800HPIB1G1E product number itself.
