DS3800HSAA1T1M

About the DS3800HSAA1T1M

The GE Dom Plus Servo Amp Board DS3800HSAA1T1M features a modular connector on 1 end and retention levers on the other end. The board is populated with a heat sink. The analog/digital converter is a component embedded on the board. The GE Dom Plus Servo Amp Board DS3800HSAA1T1M is also populated with 1 34-pin connector and 1 socket for electrically erasable programmable read-only memory (EEPROM) modules. The board is also populated with 3 trimmer resistors.

The GE Dom Plus Servo Amp Board DS3800HSAA1T1M is populated with multiple capacitors. The capacitors store current during normal drive operations. The board receives control signals that cause the capacitors to release the current. Then, the cycle begins again and the capacitors store current. This happens without user intervention and without danger to the operator or other individuals in the immediate area.

If the board is replaced, considerations must be given to the current stored in the capacitors. Before the defective board can be removed, power must be shut off to the drive. The technician must use a full featured testing device to test for the presence of power in the drive. However, when all ac and dc current is removed, the capacitors might still retain current. The high-voltage current can cause a serious shock or burn to the technician. One methods is available to remove the high-voltage from the capacitors. After power is removed from the drive, wait 30 seconds for the power to dissipate from the capacitors before touching the board.
