DS3800HSCA1E1C

About the DS3800HSCA1E1C

DS3800HSCA1E1C was created as part of the Speedtronic Mark IV series. It was made by General Electric (GE). The Mark IV series is in charge of automating and controlling gas and steam turbines.

The DS3800HSCA1E1C has twenty-one integrated circuits. These devices have several different electrical parts. Included on integrated circuits are capacitors, resistors and diodes. The letter U is used to label the integrated circuits on the board. Covering the DS3800HSCA1E1C are dozens of resistors which are multicolored and striped. The resistors are labeled with the letter R, from R1 to the R90s. Two test points are located on one side of the board, which enable the user to test the state of the board and to ensure that the board is working the correct way. Seventeen mid-sized yellow capacitors can be found on one side of the board and are labeled with the letter C. Small yellow capacitors are placed on the board which are labeled with the letter C. Many diodes which are multicolored are placed around the board which are labeled with the letters CR. Arranged line a single line on the left side of the board are eight red light-emitting diodes (LEDs). One orange light-emitting diode (LED) is situated right next to the red LEDs. The light-emitting diodes are all labeled with the letters CR, from CR2 through CR10. Sixteen transistors lined up running down the middle of the board. These transistors are labeled with the letter Q, ranging from Q1 through Q16.
