DS3800HSHB1F1D

About the DS3800HSHB1F1D

The DS3800HSHB1F1D is an input/output circuit board manufactured by General Electric. This DS3800HSHB1F1D circuit board is part of the Speedtronic Mark IV Series of circuit boards.

The Speedtronic Mark IV Series is a gas turbine control system. The Speedtronic Mark IV Gas Turbine control system monitors all turbine control and auxiliary functions and protects against unsafe operating conditions.

The DS3800HSHB1F1D is a green square-shaped circuit board. The DS3800HSHB1F1D circuit board contains multiple yellow diodes, striped multicolored resistors, black integrated circuits and a gray ribbon cable on its right side.

The Speedtronic Mark IV Gas Turbine control system was designed to maximize availability and time before a turbine forced outage. The Speedtronic Mark IV control was designed to not cause a plant shut down more frequently than once every ten years. The control was designed to allow for a failed section of the electronics to be diagnosed, repaired and returned to service while the gas turbine continues to run while being powered by the other functioning sections.

The Speedtronic Mark IV Control System was derived from the earlier Mark I and Mark II gas turbine control systems. These previous systems were based on automated turbine control, protection, and sequencing technologies that have been in use since the late 1940s. The Mark IV Control Systems is a result of these techniques, developed and improved over the last half-century.

Like all our products, the DS3800HSHB1F1D circuit board will be shipped in a static bag, which discharges any energy before handling and ensures user safety. Originally, any necessary technical support for the DS3800HSHB1F1D circuit board was provided by the manufacturer, General Electric.
