GE Mark IV Board DS3800HSQE1E1E

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DS3800HSQE1E1E to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800HSQE1E1E
  • SKU: DS3800HSQE1E1EGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

Product Description

The DS3800HSQE1E1E is a component of the Speedtronic Mark IV series which was made to control both gas and steam turbines. This component is a PCB, or printed circuit board. The DS3800HSQE1E1E was manufactured by General Electric (GE).

The DS3800HSQE1E1E contains many different types of circuit board components. The most noticeable components on the circuit board are thirty-two (32) integrated circuits. Most of the integrated circuits are small, while a few others are mid-sized and one of the integrated circuits is large. Printed on the top of the integrated circuits are the devices’ part numbers. Located on the DS3800HSQE1E1E are four (4) connector ports. One of the ports is centered on the circuit board. On the board’s right edge are two (2) other ports. 218A4637P5 and 218A4637P3, which are the part numbers of the ports, are marked on the top of the devices. The fourth port is positioned on the lower edge of the DS3800HSQE1E1E. Nine (9) light-emitting diodes, or LEDs, are placed close to the top of the DS3800HSQE1E1E. Eight (8) of the diodes are red and the last one is orange. Many capacitors in a variety of shapes, colors, and sizes can be seen on the DS3800HSQE1E1E. Many of the capacitors red, blue and silver, while others are silver and black. Over 100 small resistors are also displayed on the DS3800HSQE1E1E. These resistors are banded red and blue. Positioned near the top of the DS3800HSQE1E1E are three (3) test points. With these test points, the operator can test the device to make sure it is functioning properly.

Repair Services For DS3800HSQE1E1E

Type Lead Time Price Action
Repair Service 1-2 weeks $395

Our highly skilled technicians can repair your DS3800HSQE1E1E. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
