About the DS3800HXRA1E1E
This particular DS3800HXRA1E1E printed circuit board product offering from General Electric was originally designed and manufactured specifically for the trusted automated industrial retailer's Mark IV Turbine Control System Series, a legacy General Electric product series given the fact that its manufacture was discontinued by the original manufacturer for the reason that it was deemed to exist as a functionally-obsolete GE Mark product series as a whole in one of the many years beyond its initial Mark Series rollout. With this being the case, this DS3800HXRA1E1E device's greater Mark IV Turbine Control System Series is still quite the well-loved General Electric product series on its greater automated industrial promotional marketplace, given the fact that it is one of the trusted brand's final-developed Mark product series utilizing the Speedtronic control system technology first released alongside the advent of the initial Mark I Turbine Control System Series in the mid to later 1960s.
Hardware Tips and Specifications
The GE Series 6 Receiver Board DS3800HXRA1E1E is designed for quick installation in the drive. The board features a modular connector on 1 end and retention levers on the other end. The GE Series 6 Receiver Board DS3800HXRA1E1E also is populated with 2 40-pin connectors between the retention levers. The board is also populated with 1 34-pin connector on the board surface for connection to a daughter card, and 5 jumpers. The GE Series 6 Receiver Board DS3800HXRA1E1E supports the daughter card by supplying power to the card. The card cannot be installed in the board rack in the interior of the drive. It can only be installed on top of the board. The board has 4 plastic standoffs for installing the card. The standoffs prevent the card from touching the board while it provides a secure hardware installation. This particular DS3800HXRA1E1E printed circuit board product offering may or may not exist as the originally-devised product of its specific Mark IV Turbine Control System Series functionality, as the DS3800HXRA1E1E functional product number has been developed in an eccentric manner not necessarily making mention of any one singular Mark IV Turbine Control System Series product grouping or significant product revision.
The current for the card is carried through the 34-pin ribbon cable that is attached to the card. The other end of the ribbon cable is a plastic connector that fits in the 34-pin connector that populates the board. The GE Series 6 Receiver Board DS3800HXRA1E1E is designed so that the daughter card is adjacent to the 34-pin connector. Before you install the board with the daughter card attached, you must set the jumpers. The settings for the jumpers is recorded by the installer when the original board is installed. Locate the written record of the settings and set the jumpers on the replacement board to match. This HXRA-abbreviated printed circuit board product offering, as mentioned before, belongs to a now-obsolete legacy GE product series, and as such, is not surrounded by any great amount of originally-printed instructional manual materials online. With this being the case, alternative sources of DS3800HXRA1E1E Board hardware component and component specification information must be sourced, primarily in the form of this DS3800HXRA1E1E product's DS3800HXRA1E1E functional product number naming a number of relevant DS3800HXRA1E1E PCB details through a series of GE-developed functional naming segments. For instance, the DS3800HXRA1E1E functional product number is started through the dual-functional DS3800 series tag indirectly delegating this DS3800HXRA1E1E PCB's normal mark IV Series assembly as well as its domestic original manufacture location. Some of the other relevant hardware details in the DS3800HXRA1E1E functional product number include this DS3800HXRA1E1E product's HXRA functional product number as well as its domestic original manufacture location.
