The DS3800NADB1D1D Analog/Digital Convertor Board was manufactured for General Electric's Mark IV Turbine Control System Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3800NADB1D1D to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800NADB1D1D
  • SKU: DS3800NADB1D1DGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800NADB1D1D Technical Specifications

Manufacturer General Electric
Series Mark IV Speedtronic
Functional Part Number DS3800NADB1D1D
Functional Acronym NADB
Mark IV Series Grouping Group 1
Assembly Type Normal Assembly
Manufacturer Location Domestic

About the DS3800NADB1D1D

The DS3800NADB1D1D is a 12-bit analog/digital converter card manufactured by GE. This printed circuit board is a component in a Speedtronic Mark IV Turbine Control Series system. The Mark IV is designed for gas and steam turbine control and can sequence turbine systems and their auxiliaries for automatic start up, shut down and cool down procedures; as you most likely have been able to deduce based off of its full extended series name alone. It can also be used for air and fuel emissions control. This DS3800NADB1D1D printed circuit board product offering's greater Mark IV Series is quite the attractive General Electric product series; chiefly given the fact that it is one of General Electric's final-developed Mark product series to make use of the patented Speedtronic control system technology first seen with the introduction of the primary Mark I Series way back in the mid to later 1960s. With this being the case, the Mark IV Series that this DS3800NADB1D1D product is a component member of must be considered obsolete generally, as it is truthfully a legacy product series discontinued at some point by General Electric due to a manufacturer-identified whole series-wide functional obsolescence.

Hardware Tips and Specifications

The DS3800NADB1D1D works as the motherboard for a small daughter board (DS3800DADB.) When this auxiliary is installed the capacitance of the DS3800NADB1D1D is increased through the use of the eight 708A1 200V M/e capacitors populating that board. The DS3800NADB1D1D has one LED (amber.) It is built with three TP test points and 16 spare PTHs. The top edge of the board is marked for alignment. The board is factory drilled. It has mounting hardware in place for its daughter board. There are board extractors in place in both right side corners. The DS3800NADB1D1D has been built with both ceramic covered film resistors and with adjustable voltage potentiometers. There are several jumper switches, which allow for some customization of the board. J1 allows changes in the range.J2 changes parity. J3 changes OSC. Installation and safety guidelines for the DS3800NADB1D1D may be found within technical support publications such as data sheets and manuals. These were originally provided by General Electric. Did you know AX Control warranties many of our products? The majority of our products come with a 3-year warranty. Ask our sales staff for more information about this or other services.

While this DS3800NADB1D1D product is a member of a now-obsolete legacy General Electric product series, this means that it will not be accompanied online by the same amount of originally-printed and pertinent original instructional manual materials afforded to other General Electric Mark product series iterations such as the Mark VI Turbine Control System Series. With this lack being the case, alternative methods of DS3800NADB1D1D Board hardware component information identification must be accessed including the DS3800NADB1D1D functional product number itself, which was actually specially-developed by the trusted automated industrial machines seller to describe a number of relevant DS3800NADB1D1D Board hardware component and component specifications through its consecutive series of General Electric-formulated functional naming segments. For example, the DS3800NADB1D1D functional product number begins with the dual-functioning DS3800 series tag responsible for identifying this DS3800NADB1D1D product's normal Mark IV Series assembly as well as its more standard domestic original location of General Electric manufacture. This is followed up in the DS3800NADB1D1D functional product number by an iteration of the NADB functional product number that was created to exist as a shortened promotional representation of the DS3800NADB1D1D lengthy product number itself. The final piece of hardware information glean-able from the DS3800NADB1D1D functional product number itself is this DS3800NADB1D1D device's group one Mark IV Series product grouping.
