DS3800NDAC1E1F

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
GENERAL ELECTRIC ANALOG OUTPUT CARD

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3800NDAC1E1F to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800NDAC1E1F
  • SKU: DS3800NDAC1E1FGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

About the DS3800NDAC1E1F

The DS3800NDAC1E1F is featured in the Mark IV Speedtronic Turbine series by General Electric. The DS3800NDAC1E1F board has many labels for each part. Each part has its own outline. The DS3800NDAC1E1F includes where it was built (U.S.A.) and General Electric’s crest. The DS3800NDAC1E1F has over seventy resistors with numerous color markings (to categorize current capacity). The DS3800NDAC1E1F has eight blue boxes called Potentiometers or they are also known as Variable Resistors. Each variable resistor can be independently adjustable by a small piece on the top. The DS3800NDAC1E1F has devices called EPROM and EEPROMs. EPROMs come programmed but are able to be re-programmed as new programs become available.  The DS3800NDAC1E1F also has over ten EEPROMs. The EEPROMs come already filled with the program data for the DS3800NDAC1E1F to function. The DS3800NDAC1E1F has a pale amber light or LED, which illuminates as a current passes through it. One edge is marked A, B, C, D, E, F, G, H, and J. The DS3800NDAC1E1F has a single crystal oscillator. A crystal oscillator is utilized to create a precise frequency.  The DS3800NDAC1E1F has sixteen silvery diodes of mixed sizes one sandy diode, thirty-six blue-green diodes, and four red diodes. The DS3800NDAC1E1F has a small male port with a small colored box with two snaps plastic and a female port. The DS3800NDAC1E1F has three narrow silver fences. There are two fasteners and two points for screws to attach the DS3800NDAC1E1F to the current system set up.

Interested in a quote? Call the professional staff at AX Control today.

Repair Services For DS3800NDAC1E1F

Type Lead Time Price Action
Repair Service 1-2 weeks $305

Our highly skilled technicians can repair your DS3800NDAC1E1F. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
