DS3800NEPD1B1A

About the DS3800NEPD1B1A

The GE Excitation Power Board DS3800NEPD1B1A features a hole in each corner through which you can insert a screw to secure the board. The board is populated with multiple capacitors. The board is populated with 2 power components. The GE Excitation Power Board DS3800NEPD1B1A is also populated with 1 amber indicator LED. The board also has 1 34-pin connector and multiple wire terminals for attaching wires and components to circuits. The board is also populated with 5 trimmer resistors.

The GE Excitation Power Board DS3800NEPD1B1A has serval troubleshooting features. It is important that the drive remain online and productive and the troubleshooting features will reduce the downtime required to pinpoint the problem. This will lead to the possibility of a quick repair and a return to productivity.

The amber LED is the first indication of a problem with the drive. If the amber LED is off, it indicates that the board is processing normally without error. If the amber LED is on, it indicates that a warning has been issued. If you run the diagnostic program, the report it generates will list all errors and warnings. This includes any warnings that cause the amber LED to turn on.

One solution is to remove all power from the board and remove the board from the drive. Disconnect all cables and ribbon cables from the board and use a screwdriver to remove the screws. Keep the screws in a safe place so that they are available to use when you install the board.
