DS3800NEPD1G1D

About the DS3800NEPD1G1D

The GE Excitation Power Board DS3800NEPD1G1D features a hole in each corner through which you can insert a screw to secure the board. The board is populated with multiple capacitors. The board is populated with 2 Analog Devices power components. The GE Excitation Power Board DS3800NEPD1G1D is also populated with 1 amber indicator LED. The board also has 1 34-pin connector and multiple wire terminals for attaching wires and components to circuits. The board is also populated with 5 trimmer resistors.

The amber indicator LED in the GE Excitation Power Board DS3800NEPD1G1D is assigned an ID. The ID is IMOK, which is silk screened on the board. The LED is visible to the operator while the drive is in operation. The LED is situated near the edge of the board so that if other boards are installed around it, the amber LED is still visible. When the LED is off and the drive is receiving current, an error has occurred with the board. Check first to ensure that the board is installed properly and that current is present in the board. You can use a testing device to check for power. However, due to the high-voltage current present in the board, only a qualified servicer should use a testing device on the board while power is present.

Remove all sources of current from the drive, remove the four screws, and place the board on a dry and clear surface. The board has test points that servicer can use to test the functionality of individual circuits.
