DS3800NHVM1C1C

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
HIGH VOLT CIRCUIT BOARD GENERAL ELECTRIC

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a DS3800NHVM1C1C to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800NHVM1C1C
  • SKU: DS3800NHVM1C1CGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

About the DS3800NHVM1C1C

The DS3800NHVM1C1C is a very intricate circuit board created by General Electric as part of their Mark IV Speedtronic Turbine series. The DS3800NHVM1C1C also features thirteen relays. The relays are large black boxes that regulate how much energy the board takes in and allows the DS3800NHVM1C1C to still function even if the energy current is too strong. The DS3800NHVM1C1C also stores energy in electric fields using capacitors. The DS3800NHVM1C1C has six large metal capacitors, twelve large black capacitors, and twelve average-sized white capacitors. The DS3800NHVM1C1C has seventeen average-sized crimson diodes, twenty-six small black and silver diodes, ten average-sized black diodes, and six filmy diodes. A diode is used to have the energy flow in only one direction on the board. The DS3800NHVM1C1C also has twelve raised scarlet LEDs. An LED is also referred to as a light emitting diode. These diodes light up as the current flows through them. The DS3800NHVM1C1C has forty-eight large resistors. The base color of the resistors ranges between grey, brown and black. The DS3800NHVM1C1C also has seventeen average size resistors whose base color is light blue. The DS3800NHVM1C1C also has eleven small resistors whose base color is also light blue. Every resistor on the board has a set of up to five different colored stripes over its base color. These stripes show how much energy can go through each resistor at any given time. The DS3800NHVM1C1C has eight male ports that allow it to be connected with other circuit boards.

If you’re interested in a quote or more information please call AX Control.

Repair Services For DS3800NHVM1C1C

Type Lead Time Price Action
Repair Service 1-2 weeks $435

Our highly skilled technicians can repair your DS3800NHVM1C1C. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
