DS3800NPIA1B1B

About the DS3800NPIA1B1B

The DS3800NPIA1B1B PCB was produced by General Electric (GE). This product was made by the General Electric company. The DS3800NPIA1B1B was created to be a component of the Speedtronic Mark IV series, which may also be written as MKIV.

The MKIV is only one version in the Mark series. The Mark IV series is a system that was made for the control of gas as well as steam turbines. The Mark systems for turbine control have been utilized for turbine control years, ever since the 1960s. The Mark IV automates the turbine’s processes and protects the system from harm which may occur due to operating under conditions which may be unsafe.

The DS3800NPIA1B1B is a daughter board, which is a small circuit card which can be attached to the surface of a larger card. Adding a daughter board to another circuit board which is larger gives a device board more functions and lets the operator have more choices for operation. The DS3800NPIA1B1B daughter board is a device which is known as a high voltage input card.

The DS3800NPIA1B1B is a very small printed circuit card. Located on the surface of the DS3800NPIA1B1B are a total of 20 grey resistors. Sixteen (16) of these resistors are mid-sized. These are labeled as R for Resistor, ranging from R1 to R8 and from R11 to R18. There are also four additional smaller grey resistors. They are labeled as R for Resistor and range from R9 to R10 and R19 to R20. There are also seventeen wire links or jumpers on the surface of the DS3800NPIA1B1B.
