DS3800NPPB1M1K

About the DS3800NPPB1M1K

The DS3800NPPB1M1K is a power supply circuit board. This product is part of the Mark IV series. Mark IV was created by General Electric for the control of gas and steam turbines.

The DS3800NPPB1M1K features three (3) large black inductors, or coils. There is another smaller inductor also found on the DS3800NPPB1M1K. Five (5) large silver capacitors can be found on the DS3800NPPB1M1K. These capacitors are positioned vertically on the circuit board. Two (2) large transistors are seen near the top of the DS3800NPPB1M1K. Another large transistor connected to the circuit board with wires is located on the bottom of the board. Nine (9) small transistors are also placed around the DS3800NPPB1M1K. This circuit board also features two (2) long silver resistors which are rectangular. These resistors are labeled with their part number IRC 8850 and IRC 8943. The resistors have a resistance of ten (10) watts (10w). Positioned on the left side of the DS3800NPPB1M1K is a red switch. This switch can be used to change the current of a device. This switch can be alternated between “DISABLE” and “ENABLE”. Scattered around the DS3800NPPB1M1K are four (4) blue potentiometers. Each potentiometer features a dial which can be used to change the resistance of the device. A blue connector port is found on the left half of the DS3800NPPB1M1K. Two (2) small fuses can be seen on the left edge of the circuit board. Several series of gold jumper pins are aligned in various places throughout the DS3800NPPB1M1K. Five integrated circuits are also located around the DS3800NPPB1M1K.
