DS3800NPSK1J1K

About the DS3800NPSK1J1K

The DS3800NPSK1J1K is a printed circuit board (PCB). This board is called a power supply board. The DS3800NPSK1J1K was made for the Mark IV (MKIV) turbine control series. This is a series in the Mark system of turbine management, automation, and protection.

The DS3800NPSK1J1K features a number of different components. Along one edge of the DS3800NPSK1J1K, there is a series of twelve (12) resistor networks. These resistor networks are arranged together in a line. The resistor networks are yellow and they each contain at least two resistors inside. Below these resistor networks are a variety of small components. Several blue resistors which are small and covered in different colored bands can be found on the board. Other resistors which are also small but solid colored brown are also seen on the DS3800NPSK1J1K. There are also a couple of small yellow capacitors. On the other end of the DS3800NPSK1J1K several silver capacitors which are medium-sized can be found. On the DS3800NPSK1J1K there are also several resistors which are medium-sized. These resistors are brown and banded in various colors such as brown and white. A few small diodes which are grey and black in color can also be found on the DS3800NPSK1J1K. The most prominent components on the DS3800NPSK1J1K are centered in the middle of the board. These include a pair of large silver capacitors. These capacitors are attached upright to the circuit board. Immediately next to these capacitors is a pair of coils, also known as inductors. The inductors consist of coils of wire which are surrounded by a plastic material.
