DS3800NPSM1E1D

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.92 (12)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.92 (12)
  • Click a star to rate this product
This DS3800NPSM1E1D Power Supply Board was manufactured for General Electric's Mark IV Turbine Control System Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3800NPSM1E1D to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3800NPSM1E1D
  • SKU: DS3800NPSM1E1DGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

DS3800NPSM1E1D Technical Specifications

Manufacturer General Electric
Series Mark IV Speedtronic
Functional Part Number DS3800NPSM1E1D
Functional Description DS3800NPSM1E1D Power Supply Board

About the DS3800NPSM1E1D

The DS3800NPSM1E1D is a power supply circuit board. This product was made by General Electric. The DS3800NPSM1E1D was made to be part of the Speedtronic Mark IV. This is a printed circuit board (PCB).

Hardware Tips and Specifications

The DS3800NPSM1E1D features three (3) inductors, which are also known as coils. These inductors are marked with the designator L, from L1 to L3. Two of these inductors are situated near the top of the DS3800NPSM1E1D. The third inductor is located below these. This last inductor is topped with a black cover. This inductor is connected to the surface of the board with 6 yellow wires. Two large silver diodes are positioned on the left side of the DS3800NPSM1E1D. These diodes are connected to the circuit board by two (2) black wires each. At the bottom left side of the DS3800NPSM1E1D there are two large transistors which are silver in color. Four (4) smaller transistors are placed on the DS3800NPSM1E1D. Each transistor is marked with the letter Q. In the center of the top of the DS3800NPSM1E1D is a large blue capacitor. This capacitor is standing upright on the surface of the circuit board.

There are five (5) orange capacitors placed on the DS3800NPS1E1D. Many smaller capacitors can also be found on the surface of the circuit board. These capacitors are a variety of colors including yellow, red, and blue. All of the capacitors are labeled with the designator C. One (1) fuse is sitting on the left edge of the DS3800NPSM1E1D. Two (2) test points can be seen at the top right corner of the circuit board.
