GENERAL ELECTRIC MARK IV PC BOARD

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS3820HSMD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3820HSMD
  • SKU: DS3820HSMDGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

About the DS3820HSMD

The DS3820HSMD is part of the Speedtronic Mark IV line from General Electric. A gas or steam turbine uses a large internal combustion engine to mix fuel and air to cause a contained explosion. This explosion creates a series of gases that are under a lot of pressure and force their way out of the engine causing the turbine to move at high speed generating a great deal of energy. The energy created by the moving turbine is then harnessed and used for a multitude of other purposes. The DS3820HSMD has nine large orange capacitors and one circular red capacitor. A capacitor is used to hold extra energy in electrical fields for the DS3820HSMD to use at a later time. The DS3820HSMD has eight diodes and around ten resistors. Diodes are used to direct energy in a single direction, the resistors are used to restrict energy flow around the circuit board. The DS3820HSMD has three male terminal connectors. One male terminal is a long white terminal with ten metal pins spaced out in pairs. The other white male terminal is much smaller with six metal pins. The final male terminal port is an enclosed black terminal with roughly twenty ports. These male terminal ports are used to connect the DS3820HSMD with surrounding boards. The DS3820HSMD also has four small transistors which amplify or switch electronic signals and electrical power.

If you would like any additional information about this product or any other that AX Control offers please call the trusted team at AX Control. They will be happy to assist you with any questions.

** AX Control suggests referring to the original manufacturer's manual for all safety and installation methods.

Repair Services For DS3820HSMD

Type Lead Time Price Action
Repair Service 1-2 weeks $492

Our highly skilled technicians can repair your DS3820HSMD. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
