GENERAL ELECTRIC MARK IV PC BOARD

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a DS3820HSMD1C1F to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS3820HSMD1C1F
  • SKU: DS3820HSMD1C1FGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark IV DS3800

Product Description

If you would like any additional information about this product or any other that AX Control offers please call the trusted team at AX Control. They will be happy to assist you with any questions.

** AX Control suggests referring to the original manufacturer's manual for all safety and installation methods.

The DS3820HSMD1C1F is part of the Speedtronic Mark IV line from General Electric. The DS3820HSMD1C1F has three male terminal connectors. One male terminal is a long white terminal with ten metal pins spaced out in pairs. The other white male terminal is much smaller with six metal pins. The final male terminal port is an enclosed black terminal with roughly twenty ports. These male terminal ports are used to connect the DS3820HSMD1C1F with surrounding boards. The DS3820HSMD1C1F also has four small transistors which amplify or switch electronic signals and electrical power. The DS3820HSMD1C1F has nine large orange capacitors and one circular red capacitor. A capacitor is used to hold extra energy in electrical fields for the DS3820HSMD1C1F to use at a later time. The DS3820HSMD1C1F has eight diodes and around ten resistors. Diodes are used to direct energy in a single direction, the resistors are used to restrict energy flow around the circuit board.

A gas or steam turbine uses a large internal combustion engine to mix fuel and air to cause a contained explosion. This explosion creates a series of gases that are under a lot of pressure and force their way out of the engine causing the turbine to move at high speed generating a great deal of energy. The energy created by the moving turbine is then harnessed and used for a multitude of other purposes.

Repair Services For DS3820HSMD1C1F

Type Lead Time Price Action
Repair Service 1-2 weeks $337

Our highly skilled technicians can repair your DS3820HSMD1C1F. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
