About the 323A2374P3
The 323A2374P3 GE Display is designed as a mini terminal for use with General Electric’s Mark V turbine control system. The Mark V turbine control system has been used for managing industrial gas, steam, and wind turbines for decades, powered by General Electric's patented Speedtronic control system technology. The Mark V Turbine Control System Series is only one of several Speedtronic systems our company maintains on-hand stock for. If you need replacement parts for any of the Speedtronic systems, from the Mark I to the Mark VIe, please talk to our team or look through our online inventory for more information. This 323A2374P3 Mini-Terminal Control Display is not functionally-named as many other component products within the Mark V Series are, which means that the contents of this personalized product page with be primarily based upon a visual inspection of the model, as conducted by one of our knowledgeable and experience printed circuit board technicians.
Hardware Tips and Specifications
The 323A2374P3 is a small LCD keypad and screen combination. This 323A2374P3 product functions as a mini terminal/point of control for the Mark V Series automated drive assembly that it was originally designed and manufactured for. The 323A2374P3 unit can mount directly to a unit using screw mounts and connects with the associated plug and wiring available along one long edge of the display. While this 323A2374P3 product is a member of the Mark V Turbine Control System Series from General Electric, it is not afforded a standard version of General Electric functional product number; most likely a result of its odd existence as a keypad and LCD screen display product. With this being true, if this 323A2374P3 device makes use of any particular Mark V Series assembly version, functional product acronym, base printed circuit board coating style, or functional product revision, it is unfortunately not able to be confirmed on this 323A2374P3 personalized product page here.
The 323A2374P3 display has a single small LCD panel that offers a two-line 40 character display. Below this display, the 323A2374P3 device's front panel has four lines of touch-sensitive membrane switches. These keys offer more than one function, as they utilize the shift key located in the bottom left corner of the unit to access the secondary functions. The panel includes F1 through F20 keys, as well as scroll up and down, numeric keys, more, less, and raise/lower keys. Also included in this 323A2374P3 product offering's keypad panel are a set of three buttons seemingly pertinent to the greater Mark V Series automated drive's diagnostic fault alarm, labeled as "ALARM SIL," "ALARM ACK," and "ALARM RESET." Refer to General Electric manuals for a more detailed look at this unit as well as specifics regarding its handling and installation; this 323A2374P3 product is identifiable as a GE Drive Systems Mini-Terminal product through the insertion of several General Electric logos and the GE Drive Systems company name on the front of the 323A2374P3 keypad itself. Manuals and user guides should have been provided with your original purchase from the OEM. Our company can help with replacements if needed.
