About the DS200IAXSG1A
This DS200IAXSG1A General Electric printed circuit board product offering, as mentioned before, was originally designed and produced specifically for the Mark V Turbine Control System Series, as designated in the DS200IAXSG1A PCB's sparsely-available originally-printed instructional manual materials. This DS200IAXSG1A devices greater Mark V Series, as you may have been able to deduce based on its full extended series name, has specific applications in the control and management systems of popular and compatible wind, steam, and gas turbine automated drive assemblies, although it must concurrently be considered to exist as a now-obsolete legacy product series, given the eventual manufacturing discontinuation that took place in one of the many years past its original Mark V series roll-out. This DS200IAXSG1A printed circuit board or PCB for short's greater Mark V Series is something of a still-desirable General Electric product series on the figurative automated industrial marketplace, as it is one of the final-developed GE Mark product series to make use of the patented Speedtronic control system technology across a range of its offerings.
Hardware Tips and Specifications
The GE IGBT AA/AB Snubber Board DS200IAXSG1A features three 8-pin connectors and multiple turn screws to vary the voltage output. The turn screws on the GE IGBT AA/AB Snubber Board DS200IAXSG1A are identified with alphabetic descriptors. They are labeled PL, NL, U, V, W, PR, and NR. You can adjust the adjustment screws with a screwdriver when needed. The board also contains foil capacitors used during normal processing. Generally, these capacitors in the normal Mark V Series assembly of this DS200IAXSG1A product are part of a larger voltage limitation strategy involving a Mark V Series-standardized selection of voltage-limiting hardware components such as resistors, capacitors, diodes, and integrated circuits. It is something of a surprise that this DS200IAXSG1A printed circuit board is not considered to exist utilizing any special form of Mark V Series assembly, given the fact that it makes use of an obvious metal backplane for mounting or reinforcement purposes. Several obvious test points are permeating the normal Mark V Series assembly of this product for diagnostic fault detection purposes. This DS200IAXSG1A PCB is actually not the originally-developed product of its specific Mark V Series functional role; that would be the DS200IAXSG1 parent AA/AB Snubber Board missing this DS200IAXSG1A PCB's signature A-rated functional product revision.
The capacitors and all the components on the board are easy to break off unless the guidelines for handling the board are followed. It is shipped in a sturdy cardboard box that protects the board from normal hazards encountered during shipping. If the box has dents or has been bashed in or shows signs that liquids spilled or dripped on the box, the board might have been damaged. Open the box and gather all the written information, including warranty information, service instructions, and product information. Unless you need to install the board immediately, put it aside and out of sight so that others don’t handle it and possibly damage the board. Use a sharp blade to cut the protective bag open at one end without cutting into the board. Grasp the edge of the board and pull it out of the bag. Flatten out the bag and place the board on the bag. Wear a wrist strap when you touch the board with one end of the strap around your wrist and the other end connected to a metal object like a workbench leg or other metal object. While the general installation procedures for this DS200IAXSG1A product are certainly useful to be knowledgable of, their inclusion on this DS200IAXSG1A Board's personalized product page here is more reminiscent of this DS200IAXSG1A PCB's lack of specifically-pertinent instructional manual documentation online, which is more than likely a symptom of this DS200IAXSG1A PCB's legacy product series attribution. Given this concerted lack of originally-printed instructional documentation, the DS200IAXSG1A functional product number itself can be considered a strong original source of DS200IAXSG1A Board hardware component and component specification information; coding for various DS200IAXSG1A Board details in a series of functional naming components. For instance, the DS200IAXSG1A functional product number is started by the dual-functional DS@00 Series tag delegating this DS200IAXSG1A PCB's normal Mark V Series assembly as well as it s domestic original manufacture location. Some of the other useful hardware information revealed in the DS200IAXSG1A functional product number includes its:
- IAXS functional product abbreviation
- Normal PCB coating style
- Group one Mark V Series product grouping
- A-rated functional product revision
