About the DS200IIBDG1A
This DS200IIBDG1A General Electric printed circuit board is truly better-definable by its official functional product description as an IGBT Gate Driver Board, as it appears in original Mark V Turbine Control System Series instructional manual materials. As you could probably tell by its full name, the Mark V Series that this DS200IIBDG1A printed circuit board or PCB for short belongs to has specific applications in the management and control systems of wind, steam, and gas turbine automated drive assemblies. The Mark V Series is a legacy series as it has been discontinued in the years since its original release by the GE manufacturer, and exists as one of the final General Electric product series to feature the patented Speedtronic control system technology in its various product offerings. This DS200IIBDG1A PCB edits the original DS200IIBDG1 IGBT Gate Driver Board through its inclusion of a singular, A-rated functional product revision.
Hardware Tips and Specifications
This DS200IIBDG1A printed circuit board product offering makes use of a specific and crucial series of hardware specifications and component inclusions to gain functional status as an IGBT Gate Drive Board. The GE Insulated Gate Bipolar Transistor (IGBT) Board DS200IIBDG1A contains nine indicator LEDs that provide a status of the processing of the board. The LEDs are visible from the interior of the circuit board cabinet and are red in color when lit. When power is applied to the board and the drive is in operation the LEDs indicate the operation of the board. Since the LEDs are only visible when power is applied to the board great care must be taken when you open the cabinet. Do not touch any components in the drive while viewing the LEDs and make sure you do not drop any metal, dirt, or other debris in the DS200IIBDG1A PCB's greater Mark V Series automated drive. Before making a final purchase decision on this DS200IIBDG1A IGBT Gate Driver Board, it is of crucial importance to recognize that this DS200IIBDG1A PCB's A-rated functional product revision almost certainly alters this DS200IIBDG1A product's performance specifications and dimensions from their original, base-revised statuses. The function and application of each specific LED in this DS200IIBDG1A PCB's assembly are described in detail in the DS200IIBDG1A instructional manual materials embedded above in the manuals tab.
The GE Insulated Gate Bipolar Transistor (IGBT) Board DS200IIBDG1A has several connectors and when you install the replacement board you must make sure that you connect the cables in exactly the same connectors. To make sure you reconnect them to the same connectors, inspect the defective board and take notes that indicate the connector identifiers of the connector to which you have attached cables. Then make labels and attach them to the cables that show where to attach the cables on the new board. Also, the board contains one or more jumpers that are used to configure the board to process information in a specific way for your drive. Other jumpers are set at the factory are used at the factory for testing purposes only. The original factory-printed information that comes with the DS200IIBDG1A board identifies the jumpers and describes the jumper settings and how they change the board behavior. This particular DS200IIBDG1A product is populated by one total manually-moveable hardware jumper; this jumper is a Berg-type jumper isolated on the DS200IIBDG1A base circuit board through the J1 factory-printed nomenclature. This jumper is factory-set, so it should not be accessed or customized during normative function of the DS200IIBDG1A board, although it does select for this DS200IIBDG1A device's specific gate turn-on delay.
