About the DS200LRPBG1A
This unit is a circuit board constructed as a part of the General Electric (GE) Speedtronic series of gas turbine control systems. This series is designated as the Mark V Turbine Control System series of these reliable, high-performance electro-hydraulic control (EHC) systems. They are designed primarily for the control and management of steam and gas-powered turbines, as indicated by the above-included full extended series name. While generally pertinent to newer-developed turbine applications, this DS200LRPBG1A device's greater Mark V Series has to be considered obsolete as a whole, as it exists as a legacy Mark product series discontinued for manufactured due to a manufacturer-identified functional series obsolescence in one of the many years past its original Mark V Series rollout. This DS200LRPBG1A PCB Resolver Card's greater Mark V Series, while definable as an obsolete legacy product series, is still something of an attractive prospect on the general automated industrial marketplace, as it is one of the lastly-developed GE Mark product series to make use of the company's patented Speedtronic control system technology.
Hardware Tips and Specifications
The GE Speedtronic Mark V series of control units are outfitted with digital microprocessor modules to manage and monitor the regulation of the turbines. They are outfitted with a SIFT, or software-implemented fault tolerance, in order to increase the performance capabilities of the turbine system. The main cores of these control units are C, for communication, P, for protection, PD, for power distribution. There are also several settings for input and output capabilities. Given this DS200LRPBG1A product's above-described status as a legacy series product offering, it should come as no great surprise to discover that this DS200LRPBG1A device's originally-produced instructional manual materials are largely unavailable online. With this being true, the DS200LRPBG1A functional product number itself can be identified as a primary source of DS200LRPBG1A Board hardware component and component specification information; coding for specific details in a series of consecutive functional naming segments. Case in point, the DS200LRPBG1A functional product number actually begins with a dual-functional naming segment in the DS200 series tag describing both this DS200LRPBG1A PCB's normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other relevant hardware information reveal-able through diligent product number analysis includes this DS200LRPBG1A PCB's:
- LRPB functional product abbreviation
- Normal PCB coating style
- Group one Mark V Series product grouping
- A-rated functional product revision
The DS200LRPBG1A circuit board is a unit of the Mark V DS200 series of control components for these hydro-electric turbine systems. The Mark V is able to control and monitor the speed, temperature levels, and fire control. The DS200LRPBG1A circuit board is outfitted to operate as a resolver card circuit board within this system. The board includes terminal strips for quick I/O connections and jumpers to allow for customization of board use. Additionally, the unit has several heat sinks on board to deal with component heat. AX Control Inc. has this GE circuit board in stock in our inventory, and it is covered by our comprehensive, unparalleled warranty. To inquire about the exact length of this product, or anything else, such as delivery or the price quote offered, you can reach out to our sales representative by phone or email during our business hours. Generally, this DS200LRPBG1A printed circuit board product offering's voltage suppression and limitation strategy involves the incorporation of various Mark V Series-standardized voltage-limiting hardware components into its normal Mark V Series assembly; including various styles of capacitors, resistors, transistors, and specialized integrated circuits. This DS200LRPBG1A PCB is actually not the originally-developed product of its specific Mark V Series functionality; that would be the DS200LRPBG1 parent Resolver Card not making use of this DS200LRPBG1A product's singular A-rated functional product revision.
