This DS200PLIBG1ACA Phase Logic Interface Card was manufactured for General Electric's Mark V Speedtronic Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200PLIBG1ACA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200PLIBG1ACA
  • SKU: DS200PLIBG1ACAGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200PLIBG1ACA Technical Specifications

OEM General Electric
Series Mark V Speedtronic
Part Number DS200PLIBG1ACA
Functional Acronym PLIB
Revision Quantity 3 Revisions
Backwards-Compatibility 1st two revisions
Assembly Type Normal Assembly

About the DS200PLIBG1ACA

The DS200PLIBG1ACA is a phase logic interface card used in the Mark V Speedtronic system. This is a gas turbine control system designed for use with gas or steam turbines.  It offers full system control in either single or triple redundant architecture. To be more specific, the DS200PLIBG1ACA is often used within the EX2000 substructure of the MkV, which is used with brushless excitation systems to control ac terminal voltage. This DS200PLIBG1ACA Mark V Turbine Control System Series product's greater Mark V Series is one of the final General Electric Mark product series to utilize their patented Speedtronic control system technology, although it also exists as a now-obsolete legacy product series, due to its eventual manufacturing discontinuation in the years following its initial release. This DS200PLIBG1ACA printed circuit board product offering is not the original Mark V Series product of its specific functional role; that would be the DS200PLIBG1 parent Phase Logic Interface Card not making use of this DS200PLIBG1ACA PCB's three significant product revisions.

Hardware Tips and Specifications

As an early phase logic device, the DS200PLIBG1ACA is designed to act as an interface between the process controller’s phase logic and batch executions. The board controls phase state transitions as well as communication between these areas. The DS200PLIBG1ACA has many connectors on its surface. This includes a line of six vertical pin connectors at its center. The components are lined up parallel to the short edges of the board and parallel to each other. More connectors can be found at the top and bottom of the PCB. The DS200PLIBG1ACA is also populated by eighteen LED indicators, placed in three groups of six. There’s a single berg-type jumper located at the center top of the board. Other components include resistors, integrated circuits, resistor network arrays, diodes, and capacitors. Most are marked by reference designators. For important information regarding proper handling of the board as well as instructions for installation, please read manuals or user guides originally from General Electric. If you need more information about shipping or warranty service, or if you have questions about payment options, please refer to our website or contact our staff.

Unfortunately, because this particular DS200PLIBG1ACA printed circuit board is attributable to the now-obsolete legacy Mark V product series, many of its originally-printed instructional manuals and datasheets have been made unavailable by the manufacturer in the years following its initial production. With this being true, the DS200PLIBG1ACA functional product number itself gains a new importance to the actual DS200PLIBG1ACA board as it outlines many of this product's more basic hardware specifications. The DS200PLIBG1ACA functional product number displays this DS200PLIBG1ACA PCB's:

  • Normal Mark V Series assembly style
  • Domestic original manufacture location
  • PLIB functional product acronym
  • Normal PCB coating style
  • A-rated primary functional revision
  • C-rated secondary functional revision
  • A-rated artwork configuration revision

Frequently Asked Questions about DS200PLIBG1ACA

Where specifically was this DS200PLIBG1ACA device manufactured?

This DS200PLIBG1ACA PCB's original manufacture location can be more specifically traced to GE's Salem, Virginia factory plant location.

Has this DS200PLIBG1ACA Phase Logic Interface Board's assembly been factory-drilled in any locations?

Yes. This DS200PLIBG1ACA PCB's base board has been factory-drilled in several locations to support convenient and safe DS200PLIBG1ACA board mounting and installation.

Reviews For DS200PLIBG1ACA

Internal Review
(5.0)

This DS200PLIBG1ACA printed circuit board or PCB for short is not the original Phase Logic Interface Board created and distributed by General Electric for the Mark V Series, although this is only due to its assembly's acceptance of three functionality-enhancing product revisions that should in no way hinder its performance. Additionally, the base circuit board of this DS200PLIBG1ACA product offering should be well-protected by the normal PCB coating style that has been chemically applied to individual DS200PLIBG1ACA board components. - AX Control Lead Technician
