The DS200SHVIG1BDH is a High Voltage Interface Board that exists as a member of GE Drive System's Mark V series of drive assembly components.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a DS200SHVIG1BDH to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200SHVIG1BDH
  • SKU: DS200SHVIG1BDHGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200SHVIG1BDH Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS200SHVIG1BDH
Product Type SCR High Voltage Interface Board
Instruction Manual GEI-100160

Product Description

DS200SHVIG1BDH is a high voltage interface board developed for General Electric’s Mark V board series. This card easily mounts into a number of exciters and drives featured across the GE brand. Interfacing between the drive’s SCR bridge and the power supply board is made available when this board is installed. This card promotes communication between the drive’s integrated instrumentation card, power connect card, and power supply. This DS200SHVIG1BDH High Voltage Interface Board exists as an edited version of the original product developed by General Electric for its functional role; making use of three separate product revisions including a B-rated primary functional revision, a D-rated secondary functional revision, and an H-rated artwork configuration revision. While this DS200SHVIG1BDH product offering does make use of three separate product revisions, it is still considered to make use of a normal Mark V Series assembly style, as evidenced by the presence of the standard DS200 series tag in the DS200SHVIG1BDH functional product number.

Hardware Tips and Specifications

Voltage signals sourced to the drive are passed through this board and are sent out as system digestible signals. DS200SHVIG1BDH works to convert incoming voltage signals ranging from -500 and 500 mV. Once sent to the board, these voltage are turned into differential frequencies ranging from 0 to 500 kHz. These new frequency signals are then sent by the card to the drive’s power supply card. The card itself includes seventeen user configurable jumpers. Each jumper includes a 10:1 current transformer. These jumpers also provide additional attenuation capabilities for the user. If any of the filter fuses integrated into the board blow, three onboard LED indicator lights visually alert users. The manufacturer, General Electric, provides a set of installation parameters for both the DS200SHVIG1BDH board as well as the installing drive. Risk of user or device accidents are lessened if these guidelines are met. Drive function is dependent upon the user wiring the device correctly. Only qualified personnel should be permitted to handle and install this card. Directions on wiring this interface board can be found in the device’s manual as well as the datasheet. General Electric originally provided all members of the Mark V series with technical support.

The above information represents about the extent of original DS200SHVIG1BDH board hardware component and component specification information available from an analysis of this DS200SHVIG1BDH PCB's sparsely-available instructional manual materials, given this DS200SHVIG1BDH product offering's attribution to a now-obsolete General Electric legacy product series. With this being said, the DS200SHVIG1BDH functional product number can be considered a strong source of supplemental hardware information. Some of the DS200SHVIG1BDH board functional details revealed through the DS200SHVIG1BDH functional product number include this DS200SHVIG1BDH PCB's:

  • Normal Mark V Series assembly style
  • SHVI functional product abbreviation
  • Normal style of PCB surface coating
  • Group one Mark V Series product grouping
  • Three-fold revision history

The three-fold revision history and normal assembly style specific to this DS200SHVIG1BDH product offering have been described above in greater detail. This DS200SHVIG1BDH High Voltage Interface Board's normal PCB coating styles is a chemically-applied layer of protective PCB coating that envelops and protects individual hardware components in this DS200SHVIG1BDH product's assembly on a functional priority basis.  Our friendly and knowledgeable team at AX Control is available to assist with all of your automation needs. Availability and prices for the DS200SHVIG1BDH as well as other parts and repairs can be obtained by contacting our sales staff by phone or email.

Frequently Asked Questions about DS200SHVIG1BDH

How should I replace a DS200SHVIG1BDH?
To replace a DS200SHVIG1BDH, the best place to look is in the "procedure for replacing boards" section of the DS200SHVIG1BDH manual (Manual GEI-100170). The manual will provide you with step-by-step instructions on how to replace DS200SHVIG1BDH along with the manual providing you with general information about DS200SHVIG1BDH.
How many lights are on DS200SHVIG1BDH?
DS200SHVIG1BDH has 3 indicator lights. The lights on DS200SHVIG1BDH provide visual indication of a blow line filter fuse on DS200SHVIG1BDH.
What is the acronym for DS200SHVIG1BDH?
The acronym for DS200SHVIG1BDH is SHVI, meaning DS200SHVIG1BDH is an SCR High Voltage Interface Board.
Where can I find the manual for DS200SHVIG1BDH?
We can provide you with the manual for DS200SHVIG1BDH. The manual that goes with DS200SHVIG1BDH is Manual GEI-100160. This manual can be sent to you via manual link or manual hard copy. To get this manual, send a manual request for DS200SHVIG1BDH's manual or Manual GEI-100160.

Reviews For DS200SHVIG1BDH

Internal Review
(5.0)

As mentioned above, this DS200SHVIG1BDH High Voltage Interface Board was originally manufactured as the DS200SHVIG1 High Voltage Interface Board, notably missing all three of this DS200SHVIG1BDH versions' three significant product revisions. This DS200SHVIG1BDH product offering's H-rated artwork configuration is relatively uncommon. This DS200SHVIG1BDH PCB is available here today for both repair and replacement, and is offered for purchase with a standard three-year guaranteed PCB product warranty here. - AX Control Lead Technician
