About the DS200SLCCG1AEE
General Electric developed the DS200SLCCG1AEE card to operate as a local area network (LAN) communication card. The unit was designed for GE’s Mark V drive board series. Exciters and drives across the GE brand can have this card installed. The Mark V Series that this DS200SLCCG1AEE printed circuit board or PCB for short belongs to, as evidenced by its full extended series name, has specific applications in the management and control systems of popular and compatible wind, gas, and steam turbine automated drive assemblies. This DS200SLCCG1AEE PCB's Mark V Series, while possessing some potential alternative energy-focused applications, has to be generally described as a now-obsolete legacy product series, given its eventual manufacturing discontinuation that took place in one of the many years since its initial GE product series release. With this obsolescence being known, the Mark V Turbine Control System Series is still generally a highly-sought Mark product series on the automated industrial marketplace, as it exists as one of the final-developed GE product series to make use of the patented Speedtronic control system technology first seen alongside the release of the Mark I Series in the later 1960s.
Hardware Tips and Specifications
From the board this device provides the host drive with an interfacing space for LAN communications. The board is designed with the circuits for both ARCNET and DLAN networking interfaces. The DS200SLCCG1AEE LAN communication board provides the host drive with isolated and nonisolated circuits for communications. Signals sent to the board are filtered with the integrated LAN control processor (LCP). The board includes two EPROM memory cartridges to store programming data for the LCP. The board includes a dual ported RAM for the LCP to interface with the hosts’ drive control board. Users can easily access board diagnostics and system settings with the attached programmer. This 16 key alphanumeric programmer can be easily attached to the board. This particular DS200SLCCG1AEE printed circuit board product offering is actually not the originally-produced product of its specific Mark V Series functional role; that would be the DS200SLCCG1 parent LAN Communciations Board notably missing this DS200SLCCG1AEE PCB's three-fold revision history including two A and E-rated functional product revisions as well as a singular E-rated artwork configuration revision. Generally, voltage suppression and regulation in the normal Mark V Series assembly of this DS200SLCCG1AEE product offering would be handled by its internal assembly's adoption of a unique series of hardware components and component specifications, such as various styles of Mark V Series capacitors, diodes, rectifiers, resistors, and finally specialized integrated circuits.
Our staff at AX Control carefully wraps all boards in a protective static resistant bag before shipping. Be sure to thoroughly review the provided installation parameters provided by the manufacturer. Installation of the DS200SLCCG1AEE communication card should be performed by trained personnel qualified to handle drive boards. Refer to the device’s manual and datasheet for a comprehensive wiring guide. Technical support for this board was originally provided by General Electric. AX Control’s trusted sales team is ready to help with all of your automation needs. Please contact our team by phone or email to receive pricing information for the DS200SLCCG1AEE, or any other needed part or repair. Given this DS200SLCCG1AEE product offering's attribution to a now-obsolete legacy product series, its originally-printed instructional manual materials are generally unavailable online for the research purposes of this DS200SLCCG1AEE personalized product page. With this being true, the DS200SLCCG1AEE functional product number can be considered a strong primary source of DS200SLCCG1AEE Board hardware component and component specification information, as it codes for specific details in a consecutive series of functional naming segments. For example, the DS200SLCCG1AEE functional product number begins with the dual-functional DS200 series tag indirectly describing this DS200SLCCG1AEE PCB's normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other hardware details revealed in the DS200SLCCG1AEE functional product number includes this PCB's:
- SLCC functional product acronym
- Normal PCB coating style
- Group one Mark V Series product grouping
- A-rated primary functional product revision
- E-rated secondary functional product revision
- E-rated artwork configuration revision
