DS200TBQDG1A

Product Description

The GE RST Extension Analog Termination Board DS200TBQDG1A features 2 terminal blocks. Each block contains 107 terminals for signal wires. The GE RST Extension Analog Termination Board DS200TBQDG1A also contains multiple test points, 2 jumpers, and 3 34-pin connectors. The jumpers are identified as BJ1 and BJ2 on the board. When you first install the board, you can use the jumpers to define the processing of the board to meet the specific requirements of the drive. To do that the installer can use the information provided in the written material that came with the board. The jumpers each contain 3 pins on the board. One position is defined when two pins are covered by the jumper (for example pins 1 and 2). The other position is defined when two other pins are covered by the jumper (for example pins 2 and 3). Some jumpers support one jumper position only and cannot be moved by the installer. The alternate position is used at the factory for testing a specific circuit or function of the board.

When you are replacing the board because the original board is defective, the installer must examine the new board and the old board together and move the jumpers on the new board to the same position as found on the old board. The installer can either write down the jumper positions on the defective board and set the jumpers on the new board to be the same. Or, examine the boards side-by-side and move the jumpers on the new board to match the defective board.
