About the DS200TCDAG1BCB
The Mark V Speedtronic board known as the DS200TCDAG1BCB functions as a Digital I/O circuit board. The Mark V Turbine Control System Series is one of several turbine control systems created by General Electric under the Speedtronic umbrella. These systems were designed to offer reliable management and control of industrial gas and steam turbine systems, as evidenced by the above-attached full extended series name. While this DS200TCDAG1BCB printed circuit board product offering's greater Mark V Series has specific applications in newer-developed alternative energy assemblies, it must be considered a now-obsolete legacy product series due to its eventual manufacturing discontinuation that took place in the many years following its initial release. While a now-obsolete legacy product series, the Mark V Series that this DS200TCDAG1BCB printed circuit board or PCB for short belongs to must be classified as one of the final General Electric product series to make use of their patented Speedtronic control system technology. This DS200TCDAG1BCB PCB, while definable as a Digital I/O circuit board in its own right, is not the originally-developed product of this specific Mark V Series functionality; that would be the DS200TCDAG1 parent Digital I/O Circuit Board missing this DS200TCDAG1BCB Board's three significant product revisions.
Hardware Tips and Specifications
The DS200TCDAG1BCB functions as an interface within the Mark V systems for relay outputs and contact inputs. Use software configuration to set up how these work. The DS200TCDAG1BCB works within the <r1> core of the Mark V. It is designed to interface with and work in conjunction with boards like the STCA, UCPB, TCQA, TCQE, and TCEA boards. If you need any of these components too, please search through our inventory for these options. The DS200TCDAG1BCB board has multiple jumpers that can be used for hardware configuration. This includes the J1 jumper that is used to enable or disable the RS-232C port, the J2 and J3 jumpers for disabling IONET resistors, and the J4 through J8 jumpers for other values. Given this DS200TCDAG1BCB printed circuit board's attribution to the now-obsolete Mark V Turbine Control System Series, it should come as no surprise that this DS200TCDAG1BCB PCB is not made available surrounded by a plethora of original research materials online. With this in mind. the DS200TCDAG1BCB functional product number itself can be considered a primary source of DS200TCDAG1BCB Board hardware component and component specification information; coding for various DS200TCDAG1BCB Board details in a series of consecutive functional naming chunks. For example, the DS200TCDAG1BCB functional product number begins with the dual-functional DS200 series tag describing this DS200TCDAG1BCB product's normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other details revealed in the DS200TCDAG1BCB functional product number include this DS200TCDAG1BCB Board's:
- TCDA functional product abbreviation
- Normal PCB coating style
- Group one Mark V Series product grouping
- B-rated primary functional revision
- C-rated secondary functional revision
- B-rated artwork configuration revision
Other board components include test points, vertical pin connectors, integrated circuits, pin connectors, resistor network arrays, capacitors, and relays. Connectors are located at both the top and bottom edges. The board is marked along long and short edges for alignment and includes the GE logo to assure authenticity. Use General Electric user guides and GE manuals for additional information regarding installation guidelines and handling instructions. AX Control typically ships in-stock products within hours of receiving your purchase order. Let us know if you have special shipping instructions. Before making any singular final purchase decision on this DS200TCDAG1BCB product offering, it is crucial to understand that it has been revised from its original DS200TCDAG1 Mark V Series parent product through its attachment of a full three-fold revision table including a B-rated functional revision. a C-rated functional revision, and finally a B-rated artwork configuration revision.
