About the DS200TCPSG1AHC
This DS200TCPSG1AHC Circuit Board from General Electric exists as a Power Supply Board useful to their Mark V Turbine Control System Series; a rather self-explanatory General Electric Mark product series with specific applications in the control and management systems of General Electric-accepting gas and steam turbine automated drives. With this being true, this DS200TCPSG1AHC Power Supply Board is more specifically-attributable to the <R> core. In original General Electric instructional manual materials, this DS200TCPSG1AHC Power Supply Board plays a crucial role in converting available 125 V dc power to whatever specific voltage it may require in the greater general Mark V Series drive assembly. As with any Mark V Series product, this DS200TCPSG1AHC Power Supply Board makes use of an elevated amount of product-specific hardware elements and specifications to achieve this intended functionality, hardware elements that would be explained in detail in the following product page.
Hardware Tips and Specifications
This DS200TCPSG1AHC Power Supply Board, as mentioned above, necessitates the inclusion of several unique hardware elements to achieve true functionality as a Power Supply Board. This is seen specifically in the numerous connector types and functions made available to the DS200TCPSG1AHC Mark V Series drive system administrator. Before deciding to purchase or make a repair to this DS200TCPSG1AHC product here, it is important to consider the fact that this DS200TCPSG1AHC product's normal Mark V Series assembly version is a bit deceiving, as this DS200TCPSG1AHC Power Supply Board incorporates several printed circuit daughterboards into its assembly; daughterboards that significantly affect the overall general thickness of the DS200TCPSG1AHC product. Some of the connectors adopted into the assembly of this DS200TCPSG1AHC Power Supply Board include:
- The 2PL power supply voltage distribution connector
- The J1 TCPD 125 V dc voltage power connector
- The JC TCPD power supply diagnostics connector
- The JP1 power supply voltages connector
- The JP2 power supply voltages connector
- The X1 CCOM bus connector
All of these different connector types should be at least somewhat protected at their base connection by the basic level of protection afforded to the DS200TCPSG1AHC Power Supply Board through its normal style of printed circuit board coating. As specified in original, General Electric instructional manual materials, this DS200TCPSG1AHC Power Supply Board has no configurable hardware or software settings. Unfortunately, the above-included information is about the extent of DS200TCPSG1AHC Board hardware details available online derivable from internet-available instructional manual materials. With this being the case, the DS200TCPSG1AHC functional product number itself becomes a decently-strong source of DS200TCPSG1AHC Board hardware component and component specification detail, as it codes for specific informational nuggets through a series of General Electric-formulated functional naming segments. This series of segments begins with an initial dual-functional naming segment in the DS200 series tag indirectly asserting this DS200TCPSG1AHC boards' normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other relevant hardware details revealed through the DS200TCPSG1AHC functional product number include this TCPS-abbreviated product's TCPS functional product abbreviation, its group one Mark V Series product grouping, its normal PCB coating style, and finally its full three-fold revision history. This DS200TCPSG1AHC product would ship protected by a guaranteed warranty upon an original purchase here.
