This DS200TCQBG1 Analog Extender Card was originally designed for production within General Electric's Mark V Turbine Control Series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a DS200TCQBG1 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS200TCQBG1
  • SKU: DS200TCQBG1GBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS200TCQBG1 Technical Specifications

Manufacturer GE General Electric
Series Mark V
Part Number DS200TCQBG1
Functional Description RST Extended Analog I/O Board
Functional Acronym TCQB
PCB Coating Normal Coating

Product Description

This DS200TCQBG1 Mark V Series printed circuit board is explicitly defined in original General Electric instructional manual materials as an Analog Extender Card, as mentioned above. This particular DS200TCQBG1 printed circuit board or PCB for short is actually the very first model of Analog Extender Card manufactured by General Electric, as its assembly and DS200TCQBG1 functional product number don't seem to make any mention of any relevant product revisions. This Mark V Group One Series product offering has a normal Mark V Series assembly, also a detail retrieved from its DS200TCQBG1 functional product number.

Hardware Tips and Specifications

This DS200TCQBG1 Mark V Series product offering offers many hardware elements and specifications that are streamlined with a majority of Mark V Series printed circuit board products. The GE RST Extended Analog I/O Board DS200TCQBG1 is populated with a programmable logic device and EPROM modules. The GE RST Extended Analog I/O Board DS200TCQBG1 also has 1 OK LED that is viewable from the side, 1 50-pin connector, and 15 jumpers for supreme customization potential. The aforementioned green LED in the assembly of this DS200TCQBG1 PCB enables the operator to check the status of the board at a glance. If the LED is lit, it means the board is receiving power and is functioning. The operator can view the operations of the board from the board cabinet on the drive, along with the operations of other boards in the cabinet.

The prior information exists as about the extent of relevant DS200TCQBG1 board hardware information available on the internet in original General Electric and Mark V Turbine Control System Series instructional documentation. With this being said, this Mark V printed circuit board's DS200TCQBG1 functional product number alone is a fine source of pertinent information, including details such as:

  • A normal style of Mark V Series assembly
  • A Salem, Virginia original manufactured location
  • The TCQB functional product abbreviation
  • A normal style of printed circuit board protective coating
  • A Mark V Series Group One grouping

This DS200TCQBG1 PCB's normal style of printed circuit board coating is a thick chemically-applied layer of printed circuit board protecting that encases and protects individual hardware elements attached to this DS200TCQBG1 PCB's base board on a functional priority basis.

Frequently Asked Questions about DS200TCQBG1

What is DS200TCQBG1 used with?
DS200TCQBG1 is used in conjunction with the TCQA board.

Which part of the DS200TCQBG1 functional product number details this DS200TCQBG1 PCB's normal assembly version?

This DS200TCQBG1 printed circuit board's normal assembly version is decipherable upon inspection of its DS200TCQBG1 product number's DS200 series tag, which also identifies this Mark V Series product as a domestically-manufactured PCB.
