About the DS200TCQCG1BKG
This DS200TCQCG1BKG printed circuit board product offering from General Electric was originally designed and produced for placement in their Mark V Turbine Control System Series, as explained in the blurb above. This DS200TCQCG1BKG printed circuit board or PCB for short is described in its original General Electric instructional manual materials as a Analog IO Expander Board, although some Mark V Series fringe instructional manuals and dialogue may refer to it simply as an RST Overflow Board. This DS200TCQCG1BKG PCB is not the originally-developed product of either one of these specific functional roles; this DS200TCQCG1BKG Device is an edited version of the original DS200TCQCG1 parent Analog IO Expander Board that is missing this DS200TCQCG1BKG PCB's three significant product revisions. This DS200TCQCG1BKG PCB belongs to a rather self-explanatory General Electric product series as it has specific applications in the control and management systems of popular and compatible wind, steam, and gas turbine automated drive assemblies. While this DS200TCQCG1BKG PCB's greater Mark V Series does have some alternative energy-minded applications possibly, it has to be considered obsolete as it exists as a legacy product series discontinued by its original manufacturer in one of the many years since its original rollout.
Hardware Tips and Specifications
As with any General Electric product offering made available to our new and reconditioned extended inventory here, this DS200TCQCG1BKG printed circuit board product offering is introduced to its particular Mark V Series functional role with its internal assembly's introduction of a specific series of hardware components and component specifications. The GE RST Overflow Board DS200TCQCG1BKG is populated with 24 jumpers and 3 40-pin connectors. It also has 3 34-pin connectors and 1 16-pin connector. The ID assigned to the 16-pin connector is JC. The IDs assigned to the 40-pin connectors are JFF, JE, and 6PL. The individual signals interfaced through use of each specific connector int he assembly of this DS200TCQCG1BKG product is explained in detail in the DS200TCQCG1BKG Data Sheet attached above in our convenient manuals tab. The GE RST Overflow Board DS200TCQCG1BKG also is populated with heat sinks that dissipate heat. Consider the following information about the heat sinks before you install and remove the board. The heat sinks protrude from the board and so the board cannot be placed within 3 inches of other boards in the interior of the drive, if the boards are sandwiched together. This is to allow for clearance for the heat sinks and to give the heat sinks the air flow required to dissipate the extra heat. Another consideration is that the heat sinks might damage other boards and components when you arrange the board in the drive. You might accidentally scratch another board or knock delicate components from another board. Also, be careful to avoid scraping the board against other components and knocking off the heat sinks.
The IDs assigned to the jumpers are prefixed with BJ followed by a number. For example, jumpers are assigned IDs BJ1, BJ5, and BJ24. A description of each jumper is contained in the instructions supplied with the board from the factory. And the jumpers are referred to by the jumper ID. When the GE RST Overflow Board DS200TCQCG1BKG is originally installed in the drive the installer moves the jumpers to configure the board to meet the processing needs of the site. Generally, voltage suppression and limitation in the normal assembly of this DS200TCQCG1BKG Mark V Series product is handled by its standard selection of voltage-limiting hardware components such as various styles of capacitors, resistors, and integrated circuits. The previously-included DS200TCQCG1BKG Board context is reminiscent of any information gleaned from its very limited manual materials as well as a visual inspection of the DS200TCQCG1BKG PCB itself; necessary given this DS200TCQCG1BKG PCB's low amount of available instructional materials that comes along with its obsolete legacy product status. With this lack of research material in mind, the DS200TCQCG1BKG functional product number can be considered a strong source of DS200TCQCG1BKG Board information, as it codes for these specific details in a series of consecutive functional naming chunks. For example, the DS200TCQCG1BKG functional product number begins with the DS200 series tag delegating this DS200TCQCG1BKG PCB's normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other information revealed in the DS200TCQCG1BKG functional product number includes its:
- TCQC functional product abbreviation
- Normal PCB coating style
- Group one Mark V Series product grouping
- B-rated primary functional revision
- K-rated secondary functional revision
- G-rated artwork configuration revision
