About the DS200TCTGG1AEC
As discussed briefly in the product description inserted above, this DS200TCTGG1AEC printed circuit board or PCB for short was originally manufactured by General Electric, specifically for placement in their Mark V Turbine Control System Series. This DS200TCTGG1AEC PCB was developed specifically for the particular functional role of a Simplex Trip Board, as made obvious in its very limited instructional documentation available online. Some fringe Mark V Series manual materials may refer to this DS200TCTGG1AEC product simply as a turbine trip board. The Mark V Series that this DS200TCTGG1AEC Device belongs to, as indicated by its above-included full extended series name, has specific applications in the management and control systems of popular and compatible wind, steam, and gas turbine automated drive assemblies. While this is true, this DS200TCTGG1AEC Simplex Trip Board's greater Mark V Turbine Control System Series has to be considered a now-obsolete legacy product series, as it has been discontinued for production in one of the many years following its initial General Electric series release. Although this is the case, this DS200TCTGG1AEC Simplex Trip Board's greater Mark V Series is still quite the desirable General Electric product series, as it exists as one of the final-developed General Electric product series to make use of the company's patented Speedtronic control system technology first introduced alongside the rollout of the Mark I Series in the mid to later 1960s. This DS200TCTGG1AEC PCB is not the original product of its specific functionality manufactured for the Mark V; that would be the DS200TCTGG1 parent Simplex Trip Board missing this DS200TCTGG1AEC PCB's full three-fold revision table.
Hardware Tips and Specifications
As with any product offering made available to our extended new and reconditioned inventory of General Electric products here, this DS200TCTGG1AEC PCB's specific series functionality is induced by its internal assembly's acceptance of a specialized series of hardware components and component specifications. The GE Simplex Trip Board DS200TCTGG1AEC is populated with 21 plug-in relays. It also has 3 50-pin connectors and 2 12-pin connectors. The IDs assigned to the 50-pin connectors are JLY, JLX and JLZ. The IDs assigned to the 12-pin connectors are JN and JM. The GE Simplex Trip Board DS200TCTGG1AEC is also populated with 1 bayonet-type connector. The signal cable that connects to the bayonet-type connector contains 2 separate wires with metal bayonets on the ends. The installer inserts one wire into each connector and firmly presses it into the connector. When secure it clicks into the connector. To remove it, pull it out of the connector. Generally, voltage suppression and regulation in the normal assembly of this DS200TCTGG1AEC Mark V Series product is handled through its normal Mark V Series assembly's acceptance of a standardized series of voltage-limiting hardware components such as capacitors, resistors, diodes, and integrated circuits.
Ribbon cables connect to the 50-pin connectors. Because there are multiple 50-pin connectors, there is an opportunity to connect the 50-pin connectors incorrectly when you replace the board. Incorrect installation will prolong the time the drive is offline and possibly increase the downtime for the other equipment around the drive also. To avoid any delay, shut down the power to the drive and examine how the cables are connected to the board before you remove it. Create temporary labels from masking tape or other means and write down the ID of the connector the cable is connected to. Inspect the replacement board and notice that it is populated with connectors with the same IDs. Plan to connect the cables to the same connectors on the replacement board. Even if the board has the connectors located in different positions, the board will function the same. While this DS200TCTGG1AEC printed circuit board's various installation and replacement procedures are certainly important to be cognizant of, their inclusion on this DS200TCTGG1AEC personalized product page is truthfully more reminiscent of this DS200TCTGG1AEC product offering's lack of available originally-printed instructional manual materials. With this being the case, the DS200TCTGG1AEC functional product number can be considered a strong supplementary source of DS200TCTGG1AEC Board hardware component information; coding for specific details in a series of consecutive functional naming chunks. For instance, the DS200TCTGG1AEC functional product number begins with the dual-functional DS200 series tag delegating this DS200TCTGG1AEC PCB's normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other relevant details revealed in this DS200TCTGG1AEC PCB's functional product number includes its:
- TCTG functional product acronym
- Group one Mark V Series product grouping
- Normal PCB coating style
- A-rated primary functional revision
- E-rated secondary functional revision
- C-rated artwork configuration revision
