About the DS200UDSAG1ACC
This DS200UDSAG1ACC printed circuit board was originally manufactured, as described above, for placement in the Mark V Turbine Control System Series of respected automated industrial retailer General Electric. The Mark V Series that this DS200UDSAG1ACC printed circuit board or PCB for short belongs to, as indicated by the above-inserted full extended series name, has specific applications in the management and control systems of popular and compatible wind, gas, and steam turbine automated drive assemblies. This DS200UDSAG1ACC PCB's greater Mark V Series additionally has to be considered a now-obsolete legacy product series, as its manufactured was discontinued in the many years following its initial release due to retailer-identified obsolescence. With this being true, this DS200UDSAG1ACC printed circuit board's greater Mark V Series is still quite the highly-sought GE product series, as it exists as one of the final-produced GE Mark product series to make use of their patented Speedtronic control system technology first seen alongside the conception of the Mark I Series in the later 1960s. While this DS200UDSAG1ACC PCB is definable as a Gas Turbine Excitation Board in its own right, the originally-developed product of this specific Mark V Series functional role would be the DS200UDSAG1 parent Gas Turbine Excitation Board missing this DS200UDSAG1ACC PCB's three significant product revisions.
Hardware Tips and Specifications
The GE Excitation Board DS200UDSAG1ACC features one 1 80196 microprocessor and several erasable programmable read-only memory (EPROM) modules. The GE Excitation Board DS200UDSAG1ACC also is populated with 21 4-character displays and 32 LEDs. The EPROM modules are sensitive to static which can corrupt the information stored on them. Static can also erase the information, or damage the EPROM module. Always wear an ESD protective device when you handle EPROM modules. This provides a path for the static electricity to follow to a grounded surface. When you store the modules, place them in a static protective bag and seal the bag against dust and dirt. Keep the module in the sealed bag until you are ready to install it. To install the module, center it over the socket and gently press it into place. Inspect the installation and look for space between the module and the socket. If you see space, gently press down on the module.
The modules contain firmware and other code used by the microprocessor. The code can be erased and a new version written to the module, if desired. The code can be downloaded from the Web. However, when you replace the board, it best practice to move the modules to the replacement board. The microprocessor will have the same code to operate with in the replacement board as it used in the old board. The LEDs and the 4-character display devices provide information on the status of the board components. When the board is installed, the operator can view the board while the drive is online. While the LED and EPROM installation information pertinent to this DS200UDSAG1ACC Mark V Series product is certainly important, its placement on this DS200UDSAG1ACC personalized product page is truly more reminiscent of this DS200UDSAG1ACC PCB's lack of original instructional manual materials online for research purposes. With this being true, the DS200UDSAG1ACC functional product number itself can be identified as a strong supplementary source of DS200UDSAG1ACC Board hardware component and component specification information; coding for these details in a series of functional naming chunks. For example, the DS200UDSAG1ACC functional product number starts with the dual-functional DS200 series tag describing this DS200UDSAG1ACC PCB's normal Mark V Series assembly and domestic original manufacture location. Some of the other details revealed through this DS200UDSAG1ACC PCB's functional product number include its:
- UDSA functional product abbreviation
- Group one Mark V Series product grouping
- Normal PCB coating style
- A-rated primary functional revision
- C-rated secondary functional revision
- C-rated artwork configuration revision
