About the DS200UPLAG1ACB
As described above, this DS200UPLAG1ACB printed circuit board product offering was originally produced and designed by the trusted automated industrial retailer General Electric, specifically for placement in their Mark V Turbine Control System Series. This DS200UPLAG1ACB printed circuit board was originally developed for the specific functional role as a LAN Power Supply Board, although it is not the primarily-developed product of this specific Mark V Series functionality. The original LAN Power Supply Board developed specifically for the Mark V Turbine Control System Series is the DS200UPLAG1 parent printed circuit board missing this DS200UPLAG1ACB PCB's three significant product revisions. As you may have been able to guess based off of the above-inserted full extended series name, the Mark V Series that this DS200UPLAG1ACB Device belongs to has specific applications in the control and management systems of popular and compatible wind, gas, and steam turbine automated drive assemblies. With this DS200UPLAG1ACB PCB's newer-developed possible alternative energy applications being true, its greater Mark V Series must still be considered obsolete as it is a legacy series discontinued by General Electric in one of the many years following its initial series release. This DS200UPLAG1ACB PCB's greater Mark V Series is still highly-desired on the automated industrial marketplace, as it exists as one of the final-developed GE product series to make use of the patented Speedtronic control system technology.
Hardware Tips and Specifications
As with any printed circuit board product offering made available to our extended new and reconditioned inventory here, this DS200UPLAG1ACB PCB's Mark V Series functionality is introduced through its normal Mark V Series assembly's acceptance of a specific series of functionality-inducing hardware components and component specifications. The General Electric LAN Power Supply Circuit Board DS200UPLAG1ACB contains a pair 26-pin connectors, 1 fuse, and 1 toggle switch. The board also has one reset button and an 8-pin connector. The GE LAN Power Supply Circuit Board DS200UPLAG1ACB is 8.5 by 11 inches in size and this is designed to fit the rack in the drive. You can easily place the board in the rack and align the screw holes on the board with the screw holes in the rack. Given the fact that this DS200UPLAG1ACB printed circuit board belongs to a now-obsolete Mark legacy product series, it shouldn't come as too much of a surprise that this DS200UPLAG1ACB PCB is not surrounded by any great wealth of originally-introduced instructional documentation online. With this being true, the DS200UPLAG1ACB functional product number itself can be deemed a primary source of DS200UPLAG1ACB Board hardware component and component specification information, as it codes for specific details in a consecutive series of functional naming chunks. For example, the DS200UPLAG1ACB functional product number starts off with the dual-functional DS200 series tag describing this board's normal Mark V Series assembly as well as its domestic original manufacture location. Some of the other details revealed in the DS200UPLAG1ACB functional product number include this DS200UPLAG1ACB PCB's:
- UPLA functional product acronym
- Group one Mark V Series product grouping
- Normal PCB coating style
- A-rated primary functional revision
- C-rated secondary functional revision
- B-rated artwork configuration revision
The old board might be an older version of the same model but the dimensions of the board are the same and the new board will fit in the same position in the board rack. You might notice that the replacement board is populated with different looking components and some of the components are moved to different locations on the board. This might lead you to suspect that the old board and the replacement are incompatible or function differently. In fact, due to the extensive product testing at the factory, compatibility between the boards is assured and the replacement will provide the same functionality. The DS200UPLAG1ACB also is populated with 16 switches that enable you to configure the operation of the board. The switches are arranged in 2 blocks with 8 switches in each block. Before installing the replacement board, inspect the old board and set the switches in the same position on the replacement board. Make sure to do the same activity for the jumpers as for the replacement board.
