About the DS200UPLAG1APR2
The DS200UPLAG1APR2 is one of several GE Mark V power supply boards available within AX Control’s on-hand inventory. Please be sure you review all our offerings and order the correct version of this board for your particular application. While this board has been discontinued by the OEM (as have other Mark V components) it remains a regularly in-stock item here at AX Control. This General Electric Mark V Series product is actually not the original printed circuit board manufactured for the Mark V, as it modifies the original DS200UPLAG1 parent printed circuit board through its inclusion of two functional product revisions and a singular artwork-configuratory revision.
Hardware Tips and Specifications
The various hardware elements and specifications made available to this DS200UPLAG1APR2 LAN Power Supply Card are best-understood within the context of this device's intended functionality within its greater Mark V Series and Mark V Series drive assembly. The DS200UPLAG1APR2 is a multi-input and multi-output board that works in conjunction with other Mark V boards and supplies on-board RAM. The DS200UPLAG1APR2 board weighs approximately 3.2 pounds before it is prepared for shipping to your location. Components on the DS200UPLAG1APR2 circuit board include vertical pin connectors, d-shell connectors, and stab-on connectors. There are several variable resistors as well as multiple resistor network arrays scattered throughout the more traditional resistor component. This DS200UPLAG1APR2 LAN Power Supply Card additionally has a toggle switch close to one corner, near the board’s fuse and inductor coil; this corner also includes two heat sinks. A reset button located near the center of the board may be used to clear faults and allow some parameter changes via a hardware or hard reset. The board is marked with the General Electric logo and with the board ID number, with edges being marked to ensure proper alignment, as well as factory drilled to help with installation and mounting. Most components are marked with their original factory ID as well as a reference designation, offering the opportunity to review individual data sheets.
As alluded to before, this DS200UPLAG1APR2 LAN Power Supply Card is a General Electric Mark V Series product that makes use of its full possible table of three significant product revisions. The first two of these revision seemed to have received A and P grades respectively from their manufacturer, and are classified as functional product revisions as the enhance the performance specifications and overall functionality of the product. The third revision applied to this DS200UPLAG1APR2 product is a special R2-rated artwork revision, which focuses on the internal configuration of the hardware elements in this device's assembly.
