About the DS2020FECNRX010A
This DS2020FECNRX010A printed circuit board assembly product offering from General Electric was originally manufactured as a member of their Mark V Series, as mentioned above. The Mark V Series is a series of gas, steam, and wind turbine control and management systems and is now considered a General Electric legacy series, due to its original manufacturer's eventual discontinuation. This DS2020FECNRX010A printed circuit board or PCB for short's Mark V Turbine Control System Series, while a legacy series, is identifiable as one of the final General Electric product series to make use of their patented Speedtronic technology in its assembly. This DS2020FECNRX010A printed circuit board or PCB for short is functionally-defined in original Mark V and General Electric instructional manual materials as a Field Exciter Module, although it is not the originally-manufactured product with its intended functionality to exist within the Mark V Turbine Control System Series. The GE Mark V Series' original Field Exciter Module can be defined as the DS2020FECNRX010 Field Exciter Module, which is evidently missing this DS2020FECNRX010A product's A-rated functional product revision.
Hardware Tips and Specifications
This DS2020FECNRX010A Field Exciter Module is a General Electric product offering unique in a number of hardware component inclusions and specifications. The GE Field Exciter Board DS2020FECNRX010A features 7 jumpers and 2 terminal blocks with 3 terminals on each. The jumpers are identified as JP1 through JP7, as they are accompanied by their own individual factory-printed nomenclature labels. The GE Field Exciter Module DS2020FECNRX010A also contains multiple prong-type connectors. The board is installed on standoffs on another component of the drive. The signal wires that connect to the board originate on the component to which it is attached. While this DS2020FECNRX010A PCB may not offer a large swathe of available original instructional manual materials on the internet, it benefits nonetheless from its functional General Electric DS2020FECNRX010A product number, which codes for various hardware specification details. This DS2020FECNRX010A functional product number contains information including this DS2020FECNRX010A board's:
- Special modular style of Mark V Series assembly
- Domestic location of original manufacture
- FECN functional product abbreviation
- RX010 style of PCB protective coating
- A-rated functional product revision
The board and the component it is attached to generate heat and are designed to be connected to high-voltage current. For that reason, the drive must be situated in an environment with free flowing air that can cool the DS2020FECNRX010A module's automated drive and the components inside. Once the drive is installed you will notice if the drive remains cool or if the drive temperature causes it to reach the high temperature threshold and automatically shut off. This DS2020FECNRX010A Field Exciter Module, as explained in original Mark V Turbine Control System Series instructional documentation, provides crucial excitation for motor fields with amperages of up to 24 A, and operates with both NRX non-plugging or NRP plugging styles of field supplies. Before making a final purchase decision on this DS2020FECNRX010A printed circuit board, it is important to realize that any DS2020FECNRX010A performance specifications or dimensions on this page are primarily reminiscent of its DS2020FECNRX010 parent printed circuit board, which fails to account for the enhanced functionality encouraged in large part by this DS2020FECNRX010A PCB'a A-rated functional product revision.
