About the DS2020UCOCN1G1
The DS2020UCOCN1G1 is an N1 OC2000 Front MTG Turbine management panel. AX Control has different versions of the UCOC panel in stock, so please be sure to order the correct unit for your particular application. The DS2020UCOCN1G1 is a component within General Electric’s Mark V Speedtronic system. This system was one of the more advanced control systems designed for the management of steam and gas industrial turbines; existing as one of the final General Electric Mark product series to make use of their patented Speedtronic control system technology. The Mark V Series that this DS2020UCOCN1G1 product offering belongs to is additionally considered a General Electric legacy series, as its manufacture has been discontinued in the years following its initial release.
Hardware Tips and Specifications
The DS2020UCOCN1G1 works in conjunction with a DS2020DACAG1 Transformer assembly. You can find information about that particular unit on our website. The front panel of the DS2020UCOCN1G1 is surrounded by a silver border. The internal front panel includes multiple membrane switches organized into sections. This includes a Diagnostic Readout section that has a numeric keypad with help, escape, +/-, and increase and decrease keys, a local control panel that includes start, pre-start, offline stop, auto-enable, manual enable, alarm, raise, lower, and data keys, as well as an OC2000 panel with limit, field, and mode keys. The rear and sides of the panel include connectors like RS-232, terminal connectors, and Ethernet. The bottom back panel is open to allow for airflow to internal circuit boards. Connections between these are achieved through ribbon connectors that can be removed or attached easily. The rear of the panel has two flanges that are each drilled four times to allow for easy mounting.
The above information exists as about the extent of information revealable upon a diligent guided visual inspection of the DS2020UCOCN1G1 product offering itself. Given this DS2020UCOCN1G1 printed circuit board's lack of original instructional manual materials available online, the DS2020UCOCN1G1 functional product number itself can be considered a strong source of DS2020UCOCN1G1 Turbine Management Panel hardware component information and specifications, beginning with its dual-functional DS2020 series tag. The DS2020 series tag present at the beginning of the DS2020UCOCN1G1 functional product number reveals this DS2020UCOCN1G1 PCB to be a domestically-manufactured GE printed circuit board with a special DS2020 style of modular Mark V Series assembly. This series tag is followed in the DS2020UCOCN1G1 functional product number by an instance of the UCOC functional abbreviation, which was created to exist as a convenient promotional and conversational shorthand version of the full DS2020UCOCN1G1 product number. Immediately following the UCOC functional acronym in the DS2020UCOCN1G1 part number is the N1 series grouping tag, which also has dual naming responsibilities for this DS2020UCOCN1G1 product; declaring it to exist as a Mark V Series group one-grouped product with a special N-style of PCB protective coating. The G1 tag at the end of the DS2020UCOCN1G1 functional product number may indicate an additional normal style of protective PCB coating present in this modular product's assembly. Refer to General Electric documentation (manuals and user guides) for a more detailed look at the handling, installation, and maintenance procedures for this unit. All safety precautions should be reviewed before beginning installation.
