About the DS215DMCAG1AZZ02A
The DS215DMCAG1AZZ02A is a board component fabricated by GE for use within their Speedtronic Mark V Turbine Control System Series system. The Speedtronic line began in the late 1960s with the release of the MKI and continued development throughout the century. This DS215DMCAG1AZZ02A printed circuit board or PCB for short's greater Mark V Series has specific applications in the management and control systems of popular and compatible wind, gas, and steam turbine automated drive assemblies, and is considered a now-obsolete legacy product series given the eventual manufacturing discontinuation that took place in the many years following its initial release. While a legacy product series, the Mark V Series that this DS215DMCAG1AZZ02A PCB belongs to can still be deemed a highly-sought Mark Series from General Electric, as it exists as one of the retailer's final product series to make use of their patented Speedtronic control system technology first introduced alongside the rollout of the Mark I Series in the later 1960s. This DS215DMCAG1AZZ02A printed circuit board product is not the originally-manufactured device of its specific Mark V Series functional role; that would be the DS215DMCAG1 parent printed circuit board assembly missing this DS215DMCAG1AZZ02A PCB's A-rated functional revision and optional software packages.
Hardware Tips and Specifications
The DS215DMCAG1AZZ02A functions as a Drive board module. This board has been updated with additional hardware/firmware as compared to a similar DS200 board. It has factory-made mounting holes in each corner and is marked along the edge to allow for proper alignment. The DS215DMCAG1AZZ02A is heavily populated by components that include over fifty-five integrated circuits. Some of these chips are FGPAs (field-programmable gate arrays) while others function as oscillating chips, EPROMs, or flip-flops. Other DS215DMCAG1AZZ02A board components on the DS215DMCAG1AZZ02A include inductor coils, fourteen jumper switches, two heat sinks, a push-button switch, multiple fuse components, transistors, and multiple high-voltage electrolytic capacitors. The DS215DMCAG1AZZ02A board has four vertical male cable connectors and a single female connector. It also has several header connectors. One board edge has two LED indicators. The board uses metal film resistors as well as over twenty resistor network arrays. All of the previously-identified components in the assembly of this Mark V Series DS215DMCAG1AZZ02A module have been discovered through a visual inspection of the device itself, given this DS215DMCAG1AZZ02A PCB's attribution to a legacy product series and its concurrent lack of original instructional information online for the research purposes of this page. With this being true, the DS215DMCAG1AZZ02A functional product number itself gains a new importance, detailing various DS215DMCAG1AZZ02A board hardware traits and specifications in a series of functional naming chunks. For instance, the DS215DMCAG1AZZ02A functional product number begins with the dual-functional DS215 tag delegating this DS215DMCAG1AZZ02A PCB's special modular Mark V Series assembly as well as its domestic original manufacture location. Some of the other details revealed through the DS215DMCAG1AZZ02A functional product number include this DS215DMCAG1AZZ02A Module's:
- DMCA functional product abbreviation
- Normal PCB coating style
- Group one Mark V Series product grouping
- A-rated functional product revision
- Optional attached software package
This DS215DMCAG1AZZ02A device's Group one Mark V Series product grouping as well as its Normal PCB coating style are named in another dual-functional DS215DMCAG1AZZ02A number naming component in the G1 series grouping tag. This DS215DMCAG1AZZ02A PCB's A-rated functional product revision is considered to exist as a functional revision as it makes great improvements to this DS215DMCAG1AZZ02A PCB's assembly without sacrificing for visual purposes, instead solely focusing on functionality. The DS215DMCAG1AZZ02A board has one small vertically mounted auxiliary board with only a few components on its surface. This is located in the bottom left corner. Additionally, a larger auxiliary board can be mounted to the board's surface above a large empty area in the bottom left corner. When this card is installed the board has access to additional components. For important information regarding proper installation and handling, please consult technical support publications like manuals and user guides from GE. Before making a final purchase decision on this DS215DMCAG1AZZ02A Mark V Series product offering, it is crucial to consider that this DS215DMCAG1AZZ02A PCB has been edited from its originally-introduced performance specifications and dimensions by way of its A-rated functional product revision and optional software package.
