The DS215TCCBG8BZZ01A Turbine Control Card B with Firmware was produced by General Electric as part of the Mark V Series.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a DS215TCCBG8BZZ01A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: DS215TCCBG8BZZ01A
  • SKU: DS215TCCBG8BZZ01AGBTC
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark V DS200

DS215TCCBG8BZZ01A Technical Specifications

OEM GE General Electric
Series Mark V
Alphanumeric Part Number DS215TCCBG8BZZ01A
Functional Acronym/Abbreviation TCCB
Product Type Turbine Control Card B w/ Firmware
Repeater Types Fiber Optic Hubs
Instruction Manual GEH-6195

Product Description

Turbine Control Card B DS215TCCBG8BZZ01A is part of the Mark V Series. This model can be used in Triple Modular Redundant (TMR) or Simplex redundancy applications. Not only will this model be used in simplex or TMR redundancy applications but it will be used in either gas or steam turbine prime mover applications. When being used in steam or gas turbine prime mover applications the DS215TCCBG8BZZ01A model has the potential to have built-in diagnostic testing functions, online maintenance functions, and software-implemented fault tolerance. This Turbine Control Card B has the ability to be used in several unusual operating conditions; conditions of loss of oil, overheating, and potential overspeeding functions.

Hardware Tips and Specifications

As mentioned above the DS215TCCBG8BZZ01A model has the potential for built-in diagnostics testing, some of the diagnostic routines that can be performed are background and manually initiated diagnostic routines as well as power-up routines. There are also potential memory functions that can be used with this model, one major memory function is the EEPROM or electrically erasable programmable read-only memory which will be used in permanent and up-to-date storage application software.

While it is certainly beneficial to understand some of the software configuration options offered by this DS215TCCBG8BZZ01A Circuit Board with Firmware, given its only available functional description, the DS215TCCBG8BZZ01A alphanumeric product number itself is a strong source of relevant hardware information for this PCB. For starters, the DS215TCCBG8BZZ01A functional product number begins with the DS215 series tag, which indicates the presence of a special assembly version PCB in the Mark V Series. This DS215 series tag is followed by the TCCB functional acronym, which itself is followed by the G8 series grouping tag in the DS215TCCBG8BZZ01A product number. This series grouping tag has dual naming responsibilities for this specific PCB; detailing it as a normally-coated Mark V Series PCB with a group 8 Mark V Series grouping. This DS215TCCBG8BZZ01A Turbine Control Card B has a singular, B-rated functional revision, as indicated by the B digit that precede's this DS215TCCBG8BZZ01A product number's firmware indication. Due to no longer being actively produced the DS215TCCBG8BZZ01A model is considered obsolete but can be found in both new and used surplus at AX Control. Information regarding both shipping times and pricing quotations can be obtained from AX Control’s sales department by email or by phone number. This model also comes with a three-year warranty.

Frequently Asked Questions about DS215TCCBG8BZZ01A

How many RTDs does DS215TCCBG8BZZ01A have?
DS215TCCBG8BZZ01A has 14 RTDs. The RTDs on DS215TCCBG8BZZ01A are defaulted to the standard DIN on DS215TCCBG8BZZ01A. The actual type required for DS215TCCBG8BZZ01A depends on the requisition of DS215TCCBG8BZZ01A.
What is the nominal bus frequency for DS215TCCBG8BZZ01A?
The nominal bus frequency for DS215TCCBG8BZZ01A is 0 to 64Hz. DS215TCCBG8BZZ01A is typically at 60Hz.
How many milliamp signals are on DS215TCCBG8BZZ01A?
DS215TCCBG8BZZ01A has 14 milliamp input signals. For DS215TCCBG8BZZ01A, the signals are not typically in use. All milliamp inputs on DS215TCCBG8BZZ01A are 4 to 20 mA.
Which manual is used with DS215TCCBG8BZZ01A?
The manual used with DS215TCCBG8BZZ01A is Manual GEH-6195. This manual is the Speedtronic Mark V Turbine Control Application Manual. This manual isn't specific to DS215TCCBG8BZZ01A but the manual covers DS215TCCBG8BZZ01A specifically and the manual will guide you through applying DS215TCCBG8BZZ01A and using other Mark V cards.

Reviews For DS215TCCBG8BZZ01A

Internal Review
(5.0)

This DS215TCCBG8BZZ01A unit can be used with electrically erasable programmable read-only memory which lets the DS215TCCBG8BZZ01A model use up-to-date storage application software. This DS215TCCBG8BZZ01A printed circuit board appears in original General Electric instructional manual materials as both a Circuit Board with Firmware and as a Turbine Control Card B, although its official functional description is the latter. This DS215TCCBG8BZZ01A PCB has a special assembly version with firmware and a significant revision. - AX Control Lead Technician

Repair Services For DS215TCCBG8BZZ01A

Type Lead Time Price Action
Repair Service 1-2 weeks $585

Our highly skilled technicians can repair your DS215TCCBG8BZZ01A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
