About the DS215UPLAG1AZZ01A
As alluded to before, this DS215UPLAG1AZZ01A printed circuit board product offering was originally manufactured by General Electric, specifically for insertion in their Mark V Turbine Control System Series. As you have most likely been able to deduce based solely off of its full extended series name, the Mark V Series that this DS215UPLAG1AZZ01A product offering belongs to has specific applications in the management and control systems of popular and compatible wind, gas, and steam turbine automated drive assemblies. With this being true, the Mark V Series has to be identified as something of an obsolete General Electric product series, as it has been discontinued for manufacture in one of the many years following its initial General Electric product series release. With this being true, this DS215UPLAG1AZZ01A printed circuit board with firmware's greater Mark V Turbine Control System Series is still quite the desirable General Electric product series on the automated industrial marketplace generally; given the fact that it has specific turbine applications and is one of the final-release General Electric product series to make use of the patented Speedtronic control system technology.
Hardware Tips and Specifications
The GE Drive Systems UPLAG Board DS215UPLAG1AZZ01A features one reset button, 28 jumpers, and 2 banks of configuration switches. The GE Drive Systems UPLAG Board DS215UPLAG1AZZ01A also is populated with 2 indicator LEDs and 1 fuse. The ID of the fuse is FU1 and the fuse can be removed and installed easily if the fuse is blown. To remove the fuse, hold the fuse between your thumb and forefinger and remove it from the two-prong socket that secures it on the board. To install it, align it with the socket and press it into place. Before you replace it, make sure the fuse is blown. The filament inside the fuse is broken if the fuse is blown. If the filament is intact, the fuse does not need replacing. Before you replace the fuse, make sure you have a supply on hand of the exact type of fuse the board requires. The manual that is supplied with the board describes the exact type of fuse to install. If you install another type, you might expose the board to an over current situation that might damage the board. While fuse installation instructions for this DS215UPLAG1AZZ01A UPLAG Board are certainly important, it is important to be cognizant of the fact that their inclusion on this DS215UPLAG1AZZ01A personalized product page is truly more reminiscent of this DS215UPLAG1AZZ01A PCB's lack of pertinent instructional manual materials online for research purposes. This DS215UPLAG1AZZ01A device's greater voltage limitation strategy involves its special Mark V Series assembly's incorporation of a unique series of other votlage-limiting hardware components including different iterations of Mark V Series capacitors, resistors, transistors, diodes, and even specialized integrated circuits. For example, this DS215UPLAG1AZZ01A device's base printed circuit board incorporates several drum-style electrolytic capacitors; recognizable for both their distinctive blue color as well as their rather self-explanatory drum-like shape.
The DS215UPLAG1AZZ01A board has one green indicator LED and one red indicator LED; both included for diagnostic condition displayment. The green LED indicates that power is supplied to the board. The red LED indicates that an error has occurred. If the red LED is lit, there are several methods to troubleshoot the board. A test point is available on the board to test the function of the board. The ID of the test point is SGND CHAS1. This DS215UPLAG1AZZ01A printed circuit board is not the originally-manufactured product of its specific Mark V Series functionality; that would be the DS215UPLAG1 parent printed circuit board missing this DS215UPLAG1AZZ01A PCB's A-rated functional product revision as well as its attached optional software package. This DS215UPLAG1AZZ01A PCB's parent circuit board was discovered upon a thorough breakdown of the DS215UPLAG1AZZ01A functional product number itself; necessary as this DS215UPLAG1AZZ01A PCB is not surrounded by a plethora of manual materials. The DS215UPLAG1AZZ01A functional product number described various DS215UPLAG1AZZ01A Board hardware details in a series of consecutive functional naming chunks. For instance, this DS215UPLAG1AZZ01A functional product number begins with a dual-functional DS215 series tag describing this DS215UPLAG1AZZ01A Device's special modular assembly and domestic manufacture location. Some of the other details revealed in the DS215UPLAG1AZZ01A functional product number include this PCB's:
- UPLA functional product abbreviation
- Group one Mark V Series product grouping
- Normal PCB coating style
- A-rated functional product revision
- Attached optional software package
