About the IS200AEBMG1AFB
The IS200AEBMG1AFB circuit board is a PCB component fabricated as part of the Speedtronic Mark VI turbine control system from GE. This distributed control system was marketed by General Electric as a complete solution for the control and management of hydro, steam, and gas industrial turbine systems; a marked improvement upon earlier Mark Series iterations including the Mark V Series as it is much more wide-reaching in terms of its total applications. This IS200AEBMG1AFB Advanced Engineering Bridge Module's Mark V Series only has restricted applications in steam and gas turbine automated drive assemblies. The Mark VI Series that this IS200AEBMG1AFB device belongs to is also heralded on the greater general automated industrial marketplace for a separate reason; it is one of General Electric's final-developed Mark product series to make use of their respected Speedtronic control system technology; as technology first introduced to the automated industrial landscape with the bombastic release of the initial Mark I Series in the 1960s.
Hardware Tips and Specifications
The IS200AEBMG1AFB is comprised of a roughly rectangular board surface that has been mounted to a carrier frame. This frame, marked 1151x122OBQ01, allows the board to be more easily mounted within the VME rack system for which it was first manufactured. The board does not include a typical Mark VI front faceplate with mounting hardware to lock it into place. This mounting frame extends beyond the board’s surface on either long side with multiple screw mounts. There are also cutouts on the board that allow access to factory-drilled holes on the carrier frame’s surface. Several of these are used to secure the board to the carrier using clips and screws. Given the fact that this IS200AEBMG1AFB device is now considered a member of an obsolete legacy product series, its IS200AEBMG1AFB functional product number can actually be identified as a pretty decent source of supplemental hardware information; coding for various individual specifications in a series of GE-formulated consecutive components. The IS200AEBMG1AFB functional product number begins with the dual-functional IS200 series tag indirectly identifying this IS200AEBMG1AFB device's normal assembly version and domestic manufacture location, and delegates many other details including this IS200AEBMG1AFB product offering's:
- AEBM functional product acronym
- Normal PCB coating style
- Group one Mark VI Series product grouping
- Three-fold revision table
The IS200AEBMG1AFB Advanced Engineering Bridge Module itself is marked with reference designations, the board’s id number, the GE logo, and several identifying codes like 94V0 and E99006. The board is also marked along its edge with + and - signs and with “AC.” These correspond to the aforementioned screw mounts on the carrier frame. Components mounted to the IS200AEBMG1AFB include six vertical plug connectors, four transistors, over forty diodes, over 40 resistors that use various materials including metal film, and a dozen capacitors. Additional information about the board’s components and its use can be found using GE manuals or data sheets. AX Control can typically provide same-day shipping service for in-stock parts. Please place your order before three pm to give us time to pull and properly prepare your order for shipment. It is quite the head-scratcher to find that General Electric classified this IS200AEBMG1AFB product as having a normal style of Mark VI Series assembly, given the fact that this IS200AEBMG1AFB Advanced Engineering Bridge Module's several screw standoffs jut out of the sides of its base printed circuit board; suggesting a modular assembly and increasing the device's total surface area significantly.
