IS200AEPCH1ABC

About the IS200AEPCH1ABC

The IS200AEPCH1ABC is a PCB component part of the Speedtronic Mark VI system from GE. This contains a number of  systems, timings, and controls designed to ensure safe and reliable operation of steam and gas industrial turbine systems.

The IS200AEPCH1ABC  is a small rectangular card without a faceplate.  The board has been factory drilled in each board corner.  Each of these drill holes is ringed with a conductive material.  There are other factory-drilled holes located within the board’s body and along the edges of the board.

The IS200AEPCH1ABC is designed with a mounted auxiliary card.  This card sits almost center of the IS200AEPCH1ABC board.  It is mounted to the primary board using screws threaded through standoffs.  The auxiliary board is populated with two female connectors, with a FPGA and with other integrated circuits, and with several other connectors.  It also has capacitors, resistors, diodes, and transistors.   The auxiliary board is marked with several codes including DCOM and FA/00.

The IS200AEPCH1ABC has two barcodes attached to its surface.  The board is marked with several identifying codes.  Most components have reference designations printed nearby to allow for easy identification.  Components include three fuses, two terminal strips, integrated circuits, and multiple jack connectors of various sizes.

More information about the IS200AEPCH1ABC, its use, and how to properly install the board within the Mark VI system can be found using GE publications like user guides, data sheets, and manuals.  These publications will also provide the user with important safety information.  Only well-trained employees should maintain this equipment.
