About the IS200AVGBG1AAA
The IS200AVGBG1AAA is a printed circuit board (PCB) designed by GE as part of the Mark VI series. It is also sometimes used in the AV300i drive. The Mark VI Turbine Control System Series containing this IS200AVGBG1AAA device, as it is known at length, exists with a specific series of possible functional product applications specifically in the control and management systems of General Electric-compatible gas, steam, and wind turbine automated drive assemblies. This must be definable as quite the significant functional upgrade upon the previously-considered industry standard Mark V Turbine Control System Series of just about the exact same full extended series title, as the Mark VI Series added the alternative energy-based wind turbine possible functional application onto the gas and steam environments already made possible through this IS200AVGBG1AAA product's previous Mark V Series. This IS200AVGBG1AAA device's greater overarching Mark VI Series is also separately held in high esteem on greater promotional markets for its status as one of the final-developed GE Mark product series utilizing the patented Speedtronic control system technology across a wide range of different product offerings.
Hardware Tips and Specifications
The MKVI Speedtronic series has been used for the management of heavy-duty gas or steam turbines for decades and offers complete control via triple-redundant protection modules. The system is designed with a Windows-based operating system that includes proprietary software (CIMPLCITY/Control System Toolbox) and Ethernet capabilities. As a gate driver board in the AV300i drive, typically the drive needs three IS200AVGBG1AAA boards per each 3300,3350, 3400 or 3450 HP drive. The board is not needed for drives above or below those HP ratings. The IS200AVGBG1AAA is a smaller rectangular-shaped board with factory-made cutouts. The largest of these is rectangular-shaped and located near the center top of the board. It is spanned by a c-shaped clip connected to the board using two screws. The clip has a round mounting hole located near its center. Other drilled openings in the board are labeled LG, LE, VG, and VE. Other board components include male vertical pin connectors (two-, eight-, and six-pins) as well as transistors, metal film resistors, and ceramic capacitors. Any capacitor, resistor, transistor, diode or integrated circuit in the normal Mark VI Series assembly of this IS200AVGBG1AAA device is part of a greater voltage regulation strategy standardized to the rest of this IS200AVGBG1AAA product's Mark VI Turbine Control System Series.
For more information about proper installation and handling of the IS200AVGBG1AAA, please refer to the original datasheets or user guides provided by General Electric. If these are no longer available, it is possible AX Control can provide duplicate copies with your order. Talk to your representative. Unfortunately enough, many of this IS200AVGBG1AAA device's original instructional manual materials are actually not available online at this time due to a low general product availability. With this being the case, alternative research methods such as the IS200AVGBG1AAA functional product number itself come into play, as the IS200AVGBG1AAA functional product number codes for a number of relevant IS200AVGBG1AAA Board characteristic through a series of consecutive functional naming chunks. For example, the IS200AVGBG1AAA product number is kicked off through its inclusion fo the dual-functional IS200 series tag that is dual functional as it is responsible for delegating both this IS200AVGBG1AAA device's normal Mark VI Series assembly version on top of its more typical domestic original manufacture location. Some of the other IS200AVGBG1AAA Board qualities revealed in this fashion include its:
- AVGB functional product acronym
- Group one Mark VI Series grouping
- Normal PCB coating style
- Three-fold revision table
