About the IS200BICIH1A
The IS200BICIH1A unit was manufactured and specifically designed by General Electric and made to be a part of the GE Mark VI series. The IS200BICIH1A unit is classified as an interface card meant for use with the GE Mark VI series of SPEEDTRONIC Mark VI Turbine Control Systems, which is a system designed to completely integrate control, protection, and monitoring for generator and mechanical drive applications that operate gas and steam turbines, as is hinted at through this IS200BICIH1A device's full extended series name. The Mark VI Turbine Control System Series that this specific IS200BICIH1A product belongs to represents a significant upgrade on the Mark V Turbine Control System Series that came before, given the fact that the Mark V Series only has specific applications in more limited gas and steam turbine-based settings. With this being the case, this IS200BICIH1A device's larger Mark V Turbine Control System Series is still separately definable as an attractive General Electric Mark product series within the general automated industrial community, given the fact that it is one of the final-developed GE Mark product series to make use of the Speedtronic control system technology first seen with the advent of the Mark I Series in the mid to later 1960s.
Hardware Tips and Specifications
The IS200BICIH1A interface card controls the interfaces for the General Electric SPEEDTRONIC Mark VI Turbine Control System. There is an I/O Interface and an Operator Interface. The aforementioned I/O interface is comprised of two versions of the unit’s termination boards. One of these termination boards has two 24 point, barrier type terminal blocks which can be unplugged whenever a field maintenance event must occur. They are ready for Simplex and also TMR controls and have the ability to accept two 3.0 millimeter squared wires with 300-volt insulation. The Operator Interface, most commonly known as the Human Machine Interface (or HMI) is simply a PC which runs a Microsoft Windows NT operating system, which has supporting client-server capability, a control system toolbox for maintenance, a CIMPLICITY graphics display system, a software computing interface for the Mark VI, and even more various control systems included with the network that can be used at any point. As detailed in the IS200BICIH1A Instructional Manual made available to our handy manuals tab above, this IS200BICIH1A product is offered with a front base circuit board that makes use of several unique connectors to establish connections with various Mark VI Series offerings. Some of this IS200BICIH1A device's connectors include its:
- PFBK1 IS200GGXI Board Feedback Signals Connector
- PFBK2 IS200GGXI Board Feedback Signals Connector
- PSRC IS200GGXD Board Feedback and Gate Control Signals Connector
Each of the above-listed connectors in the normal Mark VI Series assembly of this IS200GGXD product have been named through unique combinations of their respective factory-printed nomenclature labels, their Mark VI Series interfacing potentials and compatible products, and finally the specific styles of Mark VI Series revisions that they were designed to transmit in particular. Call or email an AX Control sales representative today to inquire about the availability of the IS200BICIH1A interface card! We have the IS200BICIH1A unit in refurbished condition or possibly in new, never touched condition available in stock today for a fast and simple purchase. It is a bit of a mystery as to why this IS200BICIH1A Mark VI Turbine Control System Series product offering is not considered to utilize any special sort of Mark VI Series modular assembly, given the presence of several applicable Mark VI Series daughterboards attached to its base printed circuit board. For starters, this IS200BICIH1A product actually makes use of nineteen total printed circuit daughterboards in its seemingly-normal assembly. Eleven AOCA daugtherboards and eight total DVAA daughterboards are made available in this IS200BICIH1A device's assembly. Each of the DVAA daughterboards in this IS200BICIH1A device's assembly is designed to provide this product with two VCO circuits, while each of this IS200BICIH1A PCB's AOCA daughterboards provide seemingly-identifical comparator circuit styles.
