About the IS200BICMH1AAA
This IS200BICMH1AAA IGBT Gate Driver Card printed circuit board product offering from General Electric was originally designed and manufactured specifically for placement in the Mark VI Turbine Control System Series, and as such, exhibits a number of standard hardware specifications, such as a group one Mark VI Series product grouping. This IS200BICMH1AAA IGBT Gate Driver Card device's Mark VI Series must be treated as a significant functional upgrade upon the previously-released Mark V Turbine Control System Series of a similar full extended series name, as the Mark VI Series added the alternative energy-focused wind turbine possible functional application onto the gas and steam applications established in the earlier Mark V Turbine Series. This IS200BICMH1AAA IGBT Gate Driver Card product's Mark VI Series is also generally valued for its status as one of the final-developed GE Mark product series to utilize the patented Speedtronic control system technology.
Hardware Tips and Specifications
Model number IS200BICMH1AAA is labeled by General Electric as an IGBT Gate Driver Card. The BICM model will be used in a Mark V system. The model is equipped with a front faceplate that is labeled with the General Electric logo, the board identification, and a statement to show what slot the BICM model should be inserted into without obtaining any damage. The statement is "INSTALL IN SLOT 5 ONLY." There is also an LED indicator located on the model labeled IMOK. The IS200BICMH1AAA model also contains an abundance of user test points (TP). The test points on this model are labeled as 1A, 1B, ACOM, VMG, VDCN, VDCP, VBC, and VAB next to the first opening on the BCIM faceplate. Next to the second opening on the faceplate are TRG1, TRG, ACOM, and DA1 through DA4. The test points on this model are labeled as TP1 through TP9 and TP14 through TP16; these test points on the model are not the only points available on the model. Other components available on the IS200BICMH1AAA model are integrated circuits, around one hundred, resistors, around three hundred, and capacitors over one hundred and fifty. There are also five resistor network arrays and a single metal oxide varistor.
Unfortunately enough for the sake of this IS200BICMH1AAA IGBT Gate Driver Card personalized product page here, this IS200BICMH1AAA IGBT Gate Driver Card device is not surrounded online by any great amount of originally-produced instructional manual materials. This is more than likely attributable to the Mark VI Series' status as a frequently infringed-upon GE Mark product series. This IS200BICMH1AAA IGBT Gate Driver Card device does benefit from its General Electric manufacture though, however, as it exists with the IS200BICMH1AAA IGBT Gate Driver Card functional product number specially designed to illustrate a number of relevant IS200BICMH1AAA IGBT Gate Driver Card Board qualified through a series of consecutive functional naming components. For instance, this IS200BICMH1AAA functional product number is started through an inclusion of the dual-functional IS200 series tag delegating this IS200BICMH1AAA IGBT Gate Driver Card device's normal Mark VI Series assembly as well as its domestic location of original GE manufacture. Some of the other IS200BICMH1AAA IGBT Gate Driver Card Board qualities revealed in this manner include its:
- BICM functional product acronym
- Conformal PCB coating style
- Group one Mark VI Series product grouping
- Three-fold revision history
