About the IS200BPIHH1AAA
The IS200BPIHH1AAA is a Bridge Personality Interface Board subassembly that is part of the GE Mark VI Speedtronic system for the control of gas and steam turbine system. The Mark VI is one of the final Speedtronic systems developed by GE in a long line of systems that have offered reliable control for industrial systems for decades. This IS200BPIHH1AAA printed circuit board product offering's greater Mark VI Turbine Control System Series has to be treated as a significant functional upgrade upon the previously-developed Mark V Turbine Control System Series of more or less the exact same full series moniker, as the Mark VI Series tacked the alternative energy-based wind turbine possible functional application onto the gas and steam-based applications already seen with the rollout of the Mark V.
Hardware Tips and Specifications
The IS200BPIHH1AAA is used in Innovation Series drives and connects into a CABP board where it communicates through that and other boards. The BPIH board buffers control signals for the BICH board before they interface with the FOSB fiber-optic array. The board’s sub-assembly acts as a RS-422 interface distributor for phase-related signals as they come and go from the BICH and FOSB boards. The IS200BPIHH1AAA board has a limited number of components. The board is designed with two backplane connectors (P1 and P2) as well as three front jack connectors mounted to its front faceplate. The faceplate is connected to the circuit board using screws. The faceplate has two locking mounts that help keep the circuit board in place once it is placed within a rack system. The board also has twenty-one integrated circuits, most of which are located in a single line parallel to the front faceplate, along with resistors and capacitors. The board is marked with a barcode and board id number, and also has four blocks of test points marked off on the surface of the board (TPA, TPB, TPC and TPX.) Any resistor, capacitor, diode, fuse, or integrate circuit in the regular Mark VI Turbine Control System Series of this IS200BPIHH1AAA product is part of a greater voltage regulation ans suppression pattern standardized to the rest of this IS200BPIHH1AAA PCB's Mark VI Series.
This IS200BPIHH1AAA printed circuit board product offering or PCB for short from General Electric's heralded Mark VI Turbine Control System Series comes equipped with a standard number of important considerations to keep in mind when attempting any installation of the IS200BPIHH1AAA device. For instance, and as with any General Electric Mark VI Series product, this IS200BPIHH1AAA device should be installed or replaced with the aid of a typical wrist grounding strap. This IS200BPIHH1AAA product should be stored in an antistatic bag as well when it is not being actively used on installed, and you will notice it chips from our facility in one of these (as well as its exterior box of course). This IS200BPIHH1AAA device's IS200BPIHH1AAA functional product number can be rolled out as a decent functional source of IS200BPIHH1AAA Board hardware component and component specification information, as it was designed by GE to indicate a number of pertinent IS200BPIHH1AAA Board hardware qualities through a set of characteristic consecutive functional naming elements. For instance,, this IS200BPIHH1AAA product number begins with a standard inclusion of the dual-functional IS200 series tag indicating this IS200BPIHH1AAA PCB's normal Mark VI Series assembly as well as its domestic original location of GE manufacture. Some of the other IS200BPIHH1AAA device qualities indicated in this fashion include its:
- BPIH functional product acronym
- Group one Mark VI Series product grouping
- Conformal PCB coating style
- Three-fold unique revision table
