About the IS200CTBCG1AA
The IS200CTBCG1AA board, the Mark VI GE I/O terminal board modules, are used within systems for turbine and plant controls. The Mark VI Turbine Control System Series encapsulating this IS200CTBCG1AA product offering, as it is known at length, exists specifically with a select series of possible functional applications in the control and management systems of General Electric-compatible gas, steam. and wind turbine automated drive assemblies. This has to be described as a massive functionality-based improvement upon the previous industry-standard Mark V Turbine Control System Series of essentially the same full extended GE product series title, as the Mark V Series's basic gas and steam-based functional environments were expanded to include the alternative energy-based wind turbine functional application with the rollout of the Mark VI Series. This IS200CTBCG1AA device's Mark VI Series is also valued for its nature as one of the last-developed GE Mark product series to feature the patented Speedtronic control system technology across a range of different PCB product offerings.
Hardware Tips and Specifications
Its I/O modules possess a wide range of types and the flexibility to distribute them individually or in groupings. The IS200CTBCG1AA is a rectangular shaped terminal board, outfitted with a large plug and two strips in the middle of the board. In addition to four user-friendly programmable outputs available, the Mark VI GE I/O series drive provides three more application outputs via the terminal board. The outputs are not programmable; however, they are mapped to some commonly used signals within the drive itself. The outputs are solid-state relay drivers that can be used to drive 24 V dc, 10 mA relays. The Mark VI GE I/O series drives are mounted with an I/O pack to run algorithms, digitize the sensor signal, and communicate using a separate controller which has within it the main processor. This I/O pack has a local processor board which can run a real-time operating system and a data acquisition board that is unique to the specific I/O application. The local processor runs algorithms at faster speeds than the overall control system, such as the regulation of servo valves performed within a servo module.
Along with the features of the I/O pack, the Mark VI GE I/O series includes 100 MB full-duplex ports, Dual 100 MB Ethernet ports, online repair per I/O pack, automatic reconfiguration, accuracy specified over full operating temperature, internal temperature sensor, LEDs (which indicate power status and attention, Ethernet link-connected and communication-active, and application-specific), 28 V dc power, and an internal solid-state circuit breaker and soft start. The Mark VI GE I/O series features a controller with a compact and flexible design for processing and network communications. This controller’s features include the following: Flexible frame rate (10, 20, 40, 80, 160, or even 320 ms), speed of either 600 MHz or 1200 MHz, 5 Ethernet ports, 1 USB port, 1 COM port, flexible configuration processes (simplex, dual, triple), 18 to 32 V dc for power, status LEDs, cooling of up to 1200 MHz using redundant fans, IEC-61508 compliant safety features, and Level 1 Achilles™ certified security.
