About the IS200CTBCG1AAA
The IS200CTBCG1AAA is a General Electric Input/Output terminal board module. It is designed as part of GE Innovation Drive systems that are used in conjunction with GE’s Mark VI turbine control systems. These systems are designed to offer control for industrial gas and steam turbine systems. The Innovation Series containing this IS200CTBCG1AAA I/O Terminal Board device here is actually a subseries of the greater Mark VI Turbine Control System Series originally rolled out by GE. This IS200CTBCG1AAA I/O Terminal Board product's Mark VI Series, as it is known for short, must be defined as quite the significant functional upgrade upon the previous industry-standard Mark V Turbine Control System Series of just about the same full extended product series title, as the Mark VI Series added the alternative energy-focused wind turbine application onto the steam and gas settings seen earlier on with the rollout of the Mark V. This Mark VI Series is also generally esteemed for its status as one of GE/s final-developed Mark product series to utilize the patented Speedtronic control system technology across many products.
Hardware Tips and Specifications
The IS200CTBCG1AAA functions as an I/O card and only have a few components on its surface. The board has a single d-shell connector placed along one edge of the board and two terminal strips located on the opposite side of the board. These outputs can be used to drive signals to 10 mA 24 VDC relays located on connected boards. I/O boards are used to add input and output capabilities to systems with simple plug and play capabilities. Innovation Series drives from GE are non-regenerative drives that offer 3-level PWM performance and variable speed control. Most components in this system are designed to arrange into either a source cabinet, a load cabinet, or into a control cabinet. The voltage frequency for this system is typically 50-60 Hz with no derating and a displacement power factor of >95%. The system is designed for use within temperatures of 0 to 40 degrees Celsius in humidity levels of 5 to 95%, non-condensing. AX Control maintains an on-hand stock of industrial automation replacement parts for many manufacturers including General Electric, Reliance, Woodward, and many more. We typically can ship in-stock products within hours of your purchase. This means orders placed before 3 pm often ship the same day.
This IS200CTBCG1AAA I/O Terminal Board printed circuit board product offering from General Electric is typically not surrounded by very many originally-developed instructional manual materials onine, given its low general market availability, With this being the case, all of the IS200CTBCG1AAA I/O Terminal Board-specific hardware information stored on this IS200CTBCG1AAA I/O Terminal Board personalized product page thus far has been reminiscent of a diligent visual inspection of the IS200CTBCG1AAA I/O Terminal Board PCB itself. One other alternative medium for IS200CTBCG1AAA I/O Terminal Board information can be defined in its IS200CTBCG1AAA I/O Terminal Board functional product number, as that number was designed to illustrate a number of relevant IS200CTBCG1AAA I/O Terminal Board details through its designed series of functional naming components. For instance, this IS200CTBCG1AAA I/O Terminal Board product number begins with an iteration of the dual-functional IS200 series tag describing this IS200CTBCG1AAA I/O Terminal Board product's normal Mark VI Series assembly as well as its domestic original GE manufacture location. Some of the other relevant details indicated through this IS200CTBCG1AAA I/O Terminal Board product number include its:
- CTBC functional product acronym
- Group one Mark VI Series grouping
- Normal PCB coating style
- Three-fold revision table
