IS200DAMAG1A

About the IS200DAMAG1A

Greater Product Series Information

The IS200DAMAG1A is a printed circuit board or PCB made by General Electric (GE). This is what is known as an insulator-gate bipolar transistor. The IS200DAMAG1A is a part of the Mark VI or MKVI series by GE. This IS200DAMAG1A Insulator Gate Bipolar Transistor Board device's greater Mark VI Turbine Control System Series, as it is known at length, must be summated as:

• quite the significant functional upgrade upon the previously-highlighted industry standard of the Mark V Turbine Control System Series
  • this IS200DAMAG1A Insulator Gate Bipolar Transistor Board product's Mark VI Series was developed in part to add the more alternative energy-focused wind turbine possible functional application onto the wind and gas turbine applications made possible through the earlier-developed Mark I thru Mark IV Series

Hardware Tips and Specifications

This IS200DAMAG1A Insulator Gate Bipolar Transistor Board device's intended General Electric Mark product series functionality is introduced into its assembly in a typical manner; through the installation of numerous hardware components. Two (2) groups of components are featured on the IS200DAMAG1A:

•  On the left half of the PCB, there is a collection of components with a wide variety of part
  • Four (4) capacitors which are solid yellow are featured in this group
    •  The yellow capacitors are round. Two (2) are positioned on the left and the other two (2) are sitting on the right side.
  • Two (2) medium-sized resistors are paired together and placed in the middle of the four (4) capacitors.
    • The resistors are light blue in color and they have bands that are black, blue, grey, and red.
  • Several small resistors are featured in this group.
    • These resistors have bands that may be red, orange, yellow, blue, white, and green.
    • Two (2) small capacitors are featured in this area. These are also solid yellow in color.
  • Two (2) large metal components may be found at the bottom of the group.

Another collection of components is positioned on the right half of the IS200DAMAG1A. Two (2) large metal components are situated at the top of this group. A series of four (4) round capacitors have been placed in the center of this group. Two (2) resistors which are light blue with bands that are blue, white, and red are placed in the middle of these capacitors. Several smaller resistors are featured in this group which are also covered in multi-colored bands.
