About the IS200DRTDH1A
The IS200DRTDH1A is a PCB (printed circuit board) component manufactured by GE as part of their Mark VI Speedtronic system for the management of gas and steam turbines. “DRTD” stands for DIN-Rail Resistance Temperature Detector. The Mark VI Turbine Control System Series that this specific IS200DRTDH1A DIN-Rail Resistance Temperature Detector printed circuit board product offering can be attributed to must be defined as quite the significant functional upgrade upon the previous industry-standard-considered Mark V Turbine Control System Series of a very similar full extended GE product series title, as the Mark VI Series added the alternative energy-based wind turbine possible functional application onto the gas and steam applications seen before with the release of the Mark V. This IS200DRTDH1A DIN-Rail Resistance Temperature Detector product's Mark VI Turbine Control System Series is also generally valued for its status as one of the final-developed GE Mark product series to utilize the patented Speedtronic control system technology first seen with the initial Mark I Series rollout in 1969.
Hardware Tips and Specifications
The IS200DRTDH1A is an RTD input terminal board. This board is one of several kinds of RTD input terminal boards available for the Speedtronic Mark VI system (PRTD, TRTD, SRTD.) Many of these boards are compatible with each other. Please note the IS200DRTDH1A is not compatible with the common PRTDH1A board. RTD terminal boards act as resistance temperature detectors. They typically provide galvanic isolation or transient protection for part of the system they are attached to. Depending on the setup and type of board, RTDs can offer simplex, dual, or TMR control. The IS200DRTDH1A is a DIN-rail mounted board. It is encircled by a DIN rail carrier on all sides. The board itself is marked with codes like PLC-4, 6DA00 and 6BA01. It also has a barcode attached near one short edge. The board has very few components, but these include one d-shell female connector with screw connects to secure cable connections, a euro-block style two-level terminal block, an integrated circuit, and two rows of capacitors. The board has been drilled in two corners.
More information about the IS200DRTDH1A, including detailed information about proper installation and handling procedures, can be found via original GE documentation like manuals and datasheets. AX Control ship from our North Carolina facility daily, Monday through Friday. Orders placed before 3 pm typically ship the same day if your part is in stock. Generally, this IS200DRTDH1A DIN-Rail Resistance Temperature Detector product's originally-printed instructional manual materials are rather difficult to source online for the research purposes of this IS200DRTDH1A DIN-Rail Resistance Temperature Detector personalized product page here, due to the Mark VI Series' legacy product series status. With this being the case, the IS200DRTDH1A DIN-Rail Resistance Temperature Detector's General Electric-designed product number itself can be rolled out as a fine alternative informational source of this here IS200DRTDH1A DIN-Rail Resistance Temperature Detector's hardware component and component specification information, as it, as hinted above, was designed to illustrate a number of IS200DRTDH1A DIN-Rail Resistance Temperature Detector Board qualities through a series of consecutive functional naming elements. For instance, this product number begins with an iteration of the IS200 series tag dictating this DRTD-abbreviated product offering's normal Mark VI Series assembly as well as its domestic original manufacture location. Some of the other IS200DRTDH1A DIN-Rail Resistance Temperature Detector information revealed in this medium include its:
- DRTD functional product abbreviation
- Conformal PCB coating style
- Group one Mark VI Series product grouping
- A-rated functional product revision
