About the IS200DSFCG1AEB
The IS200DSFCG1AEB is a Shunt Feedback Board/IGBT Gate Driver that was created and marketed by GE as part of their Speedtronic Mark VI system. The Mark VI Series is a flexible management platform for gas and steam turbine industrial systems of various sizes and complexity. The Mark VI Turbine Control System Series that this IS200DSFCG1AEB printed circuit board product offering's Mark VI Turbine Control System Series belongs to has to be defined as quite the functional step up from the Mark V Turbine Control System Series of a similar full extended series name, as the Mark V Series' established gas and steam turbine-based functional applications are added on to by the wind turbine-based alternative energy functional environment. This IS200DSFCG1AEB Shunt Feedback Board's greater Mark VI Turbine Control System Series is additionally valued on greater relevant markets for its status as one of the final-developed GE Mark product series to incorporate the patented Speedtronic control system technology into a number of its different offerings.
Hardware Tips and Specifications
The Mark VI Series automated drive assembly includes an HMI/operator interface with a PC-based workstation using an MS Windows platform and dynamic graphics. The system includes GE’s proprietary Control System Toolbox for online software maintenance that allows for I/O configuration and monitoring. The IS200DSFCG1AEB is a square circuit board with multiple components. These include five LED indicators labeled DS1 through DS5, stab-on connectors, plug connectors, eyelet connectors, an isolation transformer, as well as various capacitors, diodes, resistor network arrays, resistors, transistors, and jumpers. The board is marked on two edges to allow for proper alignment. It is also marked with the GE logo and board number. Up to six of the IS200DSFCG1AEB may be needed with 1800 amp drives or bridges. 1000 amp systems take three boards. Proper orientation of the board is critical; please be sure to notate the alignment of your old boards before removing them to properly align your new part.
For more detailed information about installing the IS200DSFCG1AEB refer to manuals or data sheets originally provided by the OEM. If these are no longer available to you, AX Control may be able to provide replacements with your order. In-stock parts that are requested before 3 pm are typically shipped out on the same day. Please let your sales representative know your preferred shipping options. All available shipping options can be found on our website. Luckily enough for the purposes of this IS200DSFCG1AEB personalized product page here, this IS200DSFCG1AEB device is well-contexualized within existing Mark Series instructional documentation made available to our convenient manuals tab above. As was hinted at above, this IS200DSFCG1AEB printed circuit board product offering's LEDs are utilized to indicate different functional fault conditions. Two of the major functional faults that impact this IS200DSFCG1AEB printed circuit board in specific can be defined as the Desaturation fault, with the other existing as the Undervoltage fault. The status of this DSFC product's gate drivers is indicated by both a green and yellow LED indicator. According to original manuals, the function of these LEDs is as follows:
- The Yellow-colored LED will activate when IGBTs are driven ON
- The Green-colored LED will activate when IGBTs are driven OFF
